The XE950G PRO mining excavator delivers exceptional fuel efficiency, saving 15–25% on fuel consumption under mixed operating conditions and reducing annual operating costs by approximately 300,000 yuan. It comes standard with a 7-cubic-meter rock bucket, offering powerful performance, high efficiency under heavy loads, and rapid loading. The machine delivers stable and reliable performance, with an average availability rate consistently exceeding 95%. The cab is equipped with a suspension seat and climate control, offering excellent visibility and superior sealing.
| Model | XCMG XE950GPro (Mining / Quarries) |
|---|---|
| Operating weight | 96,200 kg (approx.) |
| Standard bucket capacity | 5.8 m³ (rock bucket) |
| Engine | Cummins QSK19-C780, net power: 585 kW @ 1900 rpm |
| Max torque | 3250 Nm @ 1400 rpm |
| Hydraulic system | Independent variable flow, max pressure 35 MPa |
| Fuel tank capacity | 1020 L |
| Max digging depth | 8,050 mm |
| Max dumping height | 10,450 mm |
| Minimum swing radius (rear) | 5,380 mm |
| Bucket digging force | 490 kN |
| Arm tearout force | 398 kN |
| Travel speed | 3.0 / 4.6 km/h (low/high) |
| Emission regulation | EU Stage V / EPA Tier 4 Final |
Equipped with a 100-ton-class four-wheel drive system, delivering a 60% improvement in wear resistance. Reinforced structures at critical points on the boom and dipper arm extend service life by 20%. Fuel consumption per cubic meter (actual volume) of material handled is reduced to 0.664 yuan. Comes standard with a 7.0 m³ reinforced bucket, designed for loading 70–90-ton wide-body trucks. Hourly fuel consumption ranges from 52 to 62 liters, which is lower than that of other machines in the same weight class.
The XE950GPro features the “XCMG Smart Mining 4.0” system, which uses IoT sensors and adaptive algorithms to optimize engine power and hydraulic flow in real time. This reduces specific fuel consumption by 9% under medium-load conditions. The electronically controlled variable-speed fan reduces external noise and energy consumption.
The main circuit uses variable-displacement piston pumps with a response time of less than 0.18 seconds. The proportional main control valve enables smooth and precise simultaneous movements, increasing cycle speed by 12% compared to the previous generation.
The XE950GPro uses high-strength HG80 and HG100 steel at critical points on the arm and boom. The pins are nitrided, which triples their wear resistance. D3-type bottom guards prevent material buildup and make cleaning easier, extending the service life of the undercarriage.
Thanks to the SCR + EGR aftertreatment system, the XE950GPro meets the most stringent environmental standards. ECO mode optimizes the power-to-fuel ratio during constant-load tasks, achieving savings of up to 5 L/h in routine operations. Maintenance intervals have been extended to 550 hours for hydraulic filters, reducing annual maintenance costs by 18%.
At copper mines in Chile and aggregate projects in Mexico, the XE950GPro achieved a mechanical availability rate of 93% over 5,000 continuous operating hours. Average fuel consumption was 37 L/h, outperforming machines in the same class. Operators highlight the excellent visibility, reduced vibrations, and intuitive 10-inch display.
XCMG’s “MinerLink” system transmits real-time telemetry data, including alerts for filter contamination, brake wear, engine temperature, and hydraulic oil level. Dealers can schedule maintenance without interrupting production. Centralized lubrication points drastically reduce service times.
The XE950GPro cab features a heated/cooled air-suspension seat, low-effort joysticks, a 10-inch LCD monitor with a multilingual interface, and a 360° camera. The interior noise level is just 71 dB(A), helping operators stay focused during long workdays. The automatic climate control system maintains a constant 22°C even in extreme outdoor conditions.
From iron ore mining in Brazil to granite quarries in Spain, the XE950GPro has been adopted by contractors who demand maximum reliability. Its compatibility with fleet management systems (FMS) enables full integration into autonomous mining environments. Loading performance for 100-ton rigid trucks is optimal: 4–5 passes with the 5.8 m³ bucket.
With over 40 spare parts distribution centers and certified technicians, XCMG guarantees the prompt supply of components for the XE950GPro. Each unit includes operator training and interactive manuals, as well as an extended warranty of 3 years or 10,000 hours.
Compared to the successful XE950GA series, the new XE950GPro offers 9% more hydraulic power, features an advanced predictive system, has a larger fuel capacity (+70 L), and boasts a 12% longer undercarriage service life. Fuel consumption is reduced by 6% during loading and hauling operations. These advantages establish the XE950GPro as the best choice for large-scale projects.
The XCMG factory is certified to ISO 9001:2015, ISO 14001, and OHSAS 45001. Every XE950GPro undergoes 24-hour continuous factory testing under maximum load. Critical welds are inspected using X-ray and ultrasonic testing, ensuring a defect-free structure.
The automatic traction control system prevents wheel spin on soft ground, while the electric parking brake enhances safety. The XE950GPro features impact protection for valves and hoses, as well as state-of-the-art LED lights for night work. All of this makes this excavator the perfect partner for mining companies looking to maximize their profitability.
The XE950GPro represents the future of sustainable mining: higher output, lower fuel consumption, and maximum durability. XCMG continues to lead the way in innovation with robust and technologically advanced solutions.
