The XE950DA is the new standard in mining excavators developed by XCMG, designed for large-scale operations in open-pit mining and quarries. With a radical focus on durability, fuel efficiency, and intelligent control technology, the XE950DA inherits the robustness of the legendary XE950GA series, incorporating significant improvements in the hydraulic system, reinforced boom structure, and high-abrasion bucket. This model offers exceptional digging capacity, reducing costs per ton moved by up to 12% compared to previous generations. The ergonomic, sound-insulated touchscreen cab, variable flow management system, and latest-generation diesel engine ensure sustainable performance that complies with environmental regulations. The XE950DA represents the perfect synergy between raw power and digital precision.
XCMG engineers have optimized every critical component: from the heavy-duty undercarriage with triple-bridge tracks to the high-torque swing system. The XE950DA features an integrated telemetry system that monitors key parameters in real time, alerting the operator to predictive maintenance needs. This excavator is built to handle extreme conditions, including dust, high temperatures, and uneven terrain. Additionally, the two-stage air filtration system and the modular design of the hydraulic units drastically reduce downtime.
The versatility of the XE950DA allows it to be equipped with various attachments: hydraulic hammers, rock buckets, rippers, and crushers. Its quick-change system makes it easy to adapt to different phases of a mining project. Power steering and an electro-hydraulic joystick provide surprising maneuverability for a machine in its class. XCMG supports the XE950DA with a global network of technical service and spare parts availability, ensuring maximum return on investment. Its optimized energy consumption reduces the carbon footprint, contributing to sustainable mining goals.
| Model | XCMG XE950DA (Mining / Quarry) |
|---|---|
| Operating Weight | 94,500 kg (approx.) |
| Bucket Capacity (standard) | 5.6 m³ (rock bucket) |
| Engine | Cummins QSK19-C760, Net power: 567 kW @ 1900 rpm |
| Max Torque | 3100 Nm @ 1400 rpm |
| Hydraulic System | Independent variable flow control, max pressure 34.3 MPa |
| Fuel Tank Capacity | 950 L |
| Max Digging Depth | 7,950 mm |
| Max Dumping Height | 10,200 mm |
| Minimum Swing Radius | 5,200 mm (rear) |
| Bucket Digging Force | 470 kN |
| Arm Tearout Force | 385 kN |
| Travel Speed | 3.2 / 4.8 km/h (low / high) |
| Emission Regulation | EU Stage V / EPA Tier 4 Final |
The XCMG XE950DA features the fifth-generation “Intelligent Power Control” system, which automatically adjusts engine power and hydraulic flow based on the workload. This reduces specific fuel consumption by up to 9% under real-world mining conditions. Additionally, its variable-speed electronic fan contributes to energy savings and lower external noise levels. The optional remote control system enables safe operations in high-risk areas, positioning the XE950DA as a benchmark in Mining 4.0.
The main circuit uses variable-displacement piston pumps with state-of-the-art pressure sensors, offering response times of less than 0.2 seconds. The main proportional control valve ensures smooth and precise simultaneous movements, reducing throttling losses. Thanks to this architecture, the XE950DA achieves a 15% increase in cycle speed compared to the previous XE950GA series.
The chassis of the XE950DA is made of high-strength HG70 and HG80 steel, robot-welded with full penetration. The articulation pins are heat-treated with nitriding, increasing service life in highly abrasive environments. D3-type undercarriage guards prevent material buildup and facilitate cleaning. The arm and rocker arm incorporate internal reinforcements to withstand extreme impact forces in hard rock mining.
The XE950DA meets the strictest environmental standards, reducing NOx and particulate emissions through the SCR + EGR system. ECO mode optimizes the power-to-fuel ratio during constant-load operations. In addition, its diesel particulate filter (DPF) regeneration system is automatic and minimizes unscheduled downtime. Maintenance intervals have been extended to 500 hours for hydraulic filter changes, reducing annual maintenance costs by approximately 18%.
In tests conducted at copper mines in Chile and coal mines in Colombia, the XE950DA achieved a mechanical availability rate of 92% over 4,000 continuous hours, exceeding the industry average. Average fuel consumption stood at 38 L/h under medium-to-high load conditions, representing a competitive advantage over machines of similar tonnage. Operators highlighted the peripheral visibility from the cab, the high-flow air conditioning system, and the reduced vibrations at the operator’s station.
Thanks to the XCMG “MinerLink” system, the XE950DA sends telemetry data to the service center: alerts regarding filter contamination, brake pad wear, engine temperature, and hydraulic oil level. The dealer can schedule maintenance without interrupting production. Centralized lubrication points reduce service times, and access to key components (radiator, batteries, pumps) is provided via non-slip platforms with safety railings.
The cab of the XE950DA features a pneumatic seat with heating and cooling, low-effort joysticks, a 10-inch LCD monitor with a multilingual interface, and a 360° camera. The climate control system maintains a stable temperature even in environments ranging from 50°C to -25°C. The interior noise level is only 72 dB(A), helping the operator stay focused during long shifts. All these features make the XE950DA a machine designed for both human and mechanical productivity.
From iron ore mining in Brazil to aggregate projects in Europe, the XE950DA has been adopted by contractors who demand maximum reliability. Its compatibility with fleet management systems (FMS) allows it to be integrated into mixed autonomous mining environments. Loading performance for 100-ton rigid trucks is optimal, completing filling cycles in 4–5 passes with a 5.6 m³ bucket. In open-pit mining, the high breakout force facilitates the loosening of compacted material.
XCMG operates spare parts distribution centers in more than 40 countries, ensuring the prompt supply of components for the XE950DA. Each unit comes with a training program for operators and technicians, interactive manuals, and an extended warranty. A philosophy of continuous improvement has established the XE series as one of the best-selling models in the over-90-ton excavator segment.
Compared to the successful XE950GA, the new XE950DA offers an 8% increase in hydraulic power, incorporates a predictive maintenance system, features a larger fuel tank (+50 L), and provides a 10% longer service life for undercarriage components. Specific fuel consumption is reduced by 5% during loading and hauling operations. These advancements establish the XE950DA as the natural evolution for large-scale projects, offering a faster return on investment and lower total cost of ownership.
The XCMG plant where the XE950DA is manufactured is certified to ISO 9001:2015, ISO 14001, and OHSAS 45001. Each unit undergoes 24-hour continuous factory testing under maximum load. Critical welds are inspected using ultrasonic and X-ray testing, ensuring a defect-free structure. The electronic systems comply with EMC regulations and IP67 protection for connectors, ensuring operation in high-humidity and dusty conditions.
