XE335C XCMG Crawler Excavator

Product Category: XCMG Crawler Excavator
Brand: XCMG
Model: XE335C
Price: $100000.00-$1000000.00 / EA Based On The Features
Delivery Time: 1-90DAYS
Supply Capacity: 1-500UNITS / Year Waiting for Your Order in Stock
Product Origin: China
After-sales Service: Engineers available to service machinery overseas
Rating:
4.9 /5 based on 177 votes

XE335C

Product Feature

The XCMG XE335C crawler excavator delivers powerful performance, is energy-efficient and environmentally friendly, and is rugged and durable, making it particularly suitable for harsh working conditions such as earthmoving and tunnel construction.

Energy-Efficient, Environmentally Friendly, and Cost-Effective
* Equipped with an Isuzu (ISUZU) engine, it features low fuel consumption, low noise, low emissions, and powerful performance.
* Utilizes a negative flow control system to maximize operational efficiency.
* The intelligent electronic control system ensures a perfect match between power output and hydraulic load.
Versatile Applications
* A variety of boom and bucket combinations maximize adaptability to different job site requirements.
* The multifunctional system meets a wide range of operational needs, including excavation and crushing.

Product Parameters

XE335C	Item	Unit	Parameters
Model	Operating weight	kg	33800
Model	Bucket capacity	m³	1.4-1.6-10
Engine	Engine model	/	ISUZU AA-6HK1XQP
	Direct injection	/	√
	4×strokes	/	√
	Water cooling	/	√
	Turbocharging	/	√
	A/A intercool	/	√
	Cylinders	/	6
	Output power of engine	Kw/rpm	190.5/2000
	Max.torque/engine	N.m/rpm	872.8/1700
	Displacement	L	7.79
Mian pertormance	Travel speed	km/h	5.5/3.3
	Slewing speed	r/min	9.7
	Gradient capability	°	≤35°
	Ground pressure	kPa	66
	Digging capacity of tcuket	kN	263
	Digging capacity of tcuket rod	kN	225
	Max.traction	kN	261
Working scope	A Max.digging height	mm	10074
	B Max.unloading height	mm	6898
	C Max.digging depth	mm	6972
	D Digging depth at the range of 8feets horizontally	mm	6728
	E Max.vertical digging depth	mm	5366
	F Max.digging radius	mm	10650
	G Max.swing height	mm	4424
Standard configuration	Boom length	mm	6400
	Length of bucket rod	mm	2670
	Bucket capacity	m³	1.4
Optional counfiguration	Length of bucket rod	mm	2900/3200/4000
Optional counfiguration	Bucket capacity	m³	1.6
