XCMG XE230C Crawler Excavator

Product Feature Of XCMG XE230C

XCMG XE230C Hydraulic Excavator (Overseas Service Available)

The XE230C hydraulic excavator features a fully hydraulic drive system, combining the high operational efficiency of a medium-sized excavator with the low fuel consumption and high maneuverability of a compact excavator. It is not only widely used domestically but also exported to more than 20 countries and regions worldwide, and its domestic sales have led the market in its class for three consecutive years.

The machine’s work equipment features a high-strength structural design and, when equipped with a reinforced bucket, can meet the demands of various earthmoving projects. Its “four wheels and one track” (carrier rollers, idler wheels, guide wheels, drive wheels, and tracks) have undergone reinforcement treatment, resulting in a service life that far exceeds that of major competitors; A high-power travel motor ensures agile operation under all working conditions; the latest hydraulic components and mechatronic control technology fully utilize engine power and achieve maximum fuel efficiency, thereby creating greater value for customers; furthermore, all routine maintenance access points are easily accessible from ground level, greatly facilitating maintenance operations.

Product Parameters Of XCMG XE230C

Model

XE230C

Bucket Capacity

m3

1.0

Standard Bucket Width

mm

1260

Operating Weight

kg

23500

Dimension

Overall length

mm

10160

Overall width

mm

2990

Overall height

mm

3050

Min.clearance

mm

485

Engine

Total displacement

L

6.494

Rated putput power

kw/rpm

125/2100

Digging Performance

Max.digging height

mm

9670

Max.dumping height

mm

6795

Max.digging depth

mm

6720

Max.vertical digging depth

mm

6165

Max.digging radius

mm

10270

Min.slewing radius

mm

3870

Min.rear slew radius

mm

2940

Bucket digging force

kn

163

Track Type

Steel



Track Width

mm

600

Travel System

Track length

mm

4255

Wheel base

mm

3462

Track gauge

mm

2390

Travel speed(GearⅠ/Ⅱ)

km/h

5.5/3.5

Gradeability

%

70

Slew Speed



rpm

12.1
