Designed specifically for harsh environments, this machine is equipped with a Perkins engine that delivers robust power and higher operational efficiency in heavy-duty applications. It offers excellent fuel economy, achieving 10–20% better fuel efficiency than comparable models. The intake system features a high-quality desert filter, enabling it to perform reliably in dusty and other harsh conditions. It comes standard with a reinforced bucket, and the boom and stick are engineered with enhanced load-bearing capacity in critical stress areas.
| Parameter | Value / Description |
|---|---|
| Model | XCMG XE1050 |
| Operating weight | 105,000 kg (approx.) |
| Engine power | 567 kW (770 HP) @ 1800 rpm |
| Engine model | Cummins QSK19 / XCMG Custom |
| Bucket capacity (standard) | 5.4 – 7.0 m³ (SAE heaped) |
| Arm digging force | 485 kN |
| Bucket breakout force | 560 kN |
| Hydraulic system pressure | 35 MPa (main) |
| Swing speed | 7.5 rpm |
| Maximum digging depth | 7,850 mm |
| Maximum reach at ground level | 12,980 mm |
| Maximum dumping height | 8,220 mm |
| Fuel tank capacity | 1,350 L |
| Shoe width | 650 mm (triple grouser) |
| Cab noise level | 72 dB(A) |
The XE1050’s hydraulic system uses load-sensing variable-displacement pumps, enabling precise control and fuel savings of up to 12% compared to conventional models. The regenerative power function in the boom and bucket harnesses kinetic energy during lowering, reducing the load on the engine. In addition, the intelligent cooling system automatically adjusts fan speed based on oil and coolant temperature, maximizing efficiency and extending component life.
The heavy-duty undercarriage features sealed and lubricated tracks, specially heat-treated upper and lower rollers, and large-diameter guide wheels. The main frame has undergone finite element analysis to distribute stresses evenly, preventing stress concentrations. The XE1050 is equipped with an advanced XCMG “X-Cloud” monitoring system, which enables real-time telemetry and predictive maintenance.
The XE1050’s FOPS/ROPS cab protects the operator from impacts and rollovers. The air-suspension seat with heating reduces fatigue during long shifts. Panoramic visibility is enhanced by 360° cameras and a proximity detection system. The automatic climate control system maintains a constant temperature even in extreme dust and heat conditions. The control panel features a 10-inch touchscreen that displays fuel consumption, pressures, and service alerts.
A 770-horsepower engine with instant response, ideal for tough conditions.
Adaptive ECO and PWR modes, reducing energy consumption by up to 10%.
Grouped filters and centralized ground-level lubrication points.
Remote diagnostics and real-time fleet management.
The XE1050 excavator is designed to load 60- to 90-ton rigid dump trucks in an average of 4–5 passes. Its working radius and penetration force make it ideal for extracting iron ore, copper, coal, and quarry materials. Thanks to its compatibility with various buckets and attachments (hydraulic hammer, ripper), the XE1050 can be used for primary demolition and bench preparation. The boom and arm structure has been optimized for hammer work, incorporating standard piping and check valves.
In high-altitude applications, the variable-geometry turbocharger maintains rated power without significant losses. The engine preheating system and intake heater ensure reliable starts at -25 °C. In addition, the high-capacity air filtration package (dual-element) extends cleaning intervals even in extremely dusty environments.
The XE1050 complies with EPA Tier 4 Final and EU Stage V regulations through an SCR system with AdBlue and a diesel particulate filter (DPF). Biodegradable hydraulic oil is available as an option for environmentally sensitive areas. External noise reduction is significant thanks to the sound-insulating enclosure of the engine compartment. XCMG designed this machine with the goal of reducing its carbon footprint without sacrificing productivity.
Field studies show that the XE1050 can move up to 15% more material per liter of fuel compared to its direct competitors. The durability of key components (engine, pumps, final drives) allows for longer service intervals (500 hours). Ownership costs are significantly reduced thanks to the availability of genuine XCMG spare parts and the global service network. Software updates are performed remotely, avoiding unnecessary downtime.
The boom and arm structure utilizes high-strength steel plates with robotic welding, ensuring superior structural integrity. The main pump’s electronic control system adjusts oil flow in milliseconds, achieving smooth and precise movements that reduce operator and machine wear. The counterweight design and mass distribution ensure optimal stability even with the bucket fully loaded at maximum reach.
In short, XCMG’s XE1050 is not only a high-performance mining excavator but also a smart platform that adapts to the evolving needs of the mining industry. Its combination of ruggedness, cutting-edge technology, and ease of maintenance makes it one of the most competitive options on the market for large-scale mining operations. The reliability of XCMG’s components and after-sales support provide the peace of mind needed to tackle the most ambitious projects.
XCMG XE1050 — Uncompromising Power
