XCMG Toolbox Assembly

The XCMG Toolbox Assembly is a crucial component in XCMG’s equipment lineup, designed to provide a secure and organized storage solution for tools. It is crafted with precision and a variety of components to ensure durability and functionality, meeting the high – standards required in the construction and industrial sectors.

Product Description of XCMG Toolbox Assembly

Structural Components
The TANK BODY forms the main structure of the toolbox. It is robustly built to withstand the rigors of daily use and protect the tools inside. There are two instances of the TANK BODY, which may be part of a multi – layer or a complex design. The COVER is used to enclose the toolbox, safeguarding the tools from dust, debris, and the elements. It is attached to the tank body in a way that allows for easy access when needed.
Fastening and Connecting Elements
Fastening is a key aspect of the toolbox assembly. The M10×25 SCREW and M10×25 BOLT, along with the M10×30 10.9 BOLT and M8×20 10.9 M8×20 BOLT, are used to secure different parts of the toolbox together. These bolts and screws are of high – quality, designed to resist corrosion and provide a strong connection. Washers play an important role in the assembly. The 10 WASHER and 8 WASHER are used in multiple locations. They are placed between the bolts and the components to distribute the load evenly, prevent loosening, and protect the surfaces from damage. The M10 NUT is used in conjunction with the M10 bolts to tighten the connections securely.
Safety and Protective Features
The ANTI – SKID PLATE is installed on the toolbox to enhance safety. It provides better traction, reducing the risk of slipping when workers are accessing the toolbox. The SEALING STRIPS are used around the edges of the cover and other openings. They help in creating a tight seal, preventing water and dust from entering the toolbox and protecting the tools inside.
Operational Components
The LOCK is an essential part of the toolbox assembly. It ensures the security of the tools by preventing unauthorized access. The PULL – ROD is used to operate the cover, allowing for easy opening and closing. The CATCH is used to hold the cover in place when it is closed, ensuring that it does not accidentally open during transportation or operation.
Auxiliary Components
The JACKET may be used for additional protection or insulation of the toolbox. The 2.5×14 PIN is likely used for connecting or aligning specific components within the assembly. The FAN PAD could be used for ventilation or cooling purposes, especially if there are heat – generating tools stored inside. The BOARDING might be a part of the access structure, facilitating easy reach to the tools.

The XCMG Toolbox Assembly is a well – engineered product that combines multiple components to provide a reliable and functional storage solution for tools. Each part, from the TANK BODY to the FAN PAD, plays a vital role in the overall performance, safety, and usability of the toolbox.

Product Parameters of XCMG Toolbox Assembly

ITEM	PART NO.	PART NAME	Q’TY	IA	REPLACE PART
1	805139858	M10×25 SCREW	2	IA	PART NO.	Q’TY
2	805338260	10 WASHER	2
3	805338279	10 WASHER	2	I	805339279	0
4	310705440	TANK BODY	1
5	310705443	ANTI-SKID PLATE	1
6	805011330	M10×25 BOLT	6
7	310705437	COVER	1
8	819906631	LOCK	1
9	805238371	M10 NUT	6
10	310705442	JACKET	2
11	310705459	TANK BODY	1
12	805046416	M10×30 10.9 BOLT	8
13	805338268	10 WASHER	6
14	805603553	2.5×14 PIN	2
15	310705448	PULL-ROD	1
16	805338266	8 WASHER	6
17	310705445	CATCH	1
18	800104439	SEALING STRIPS	1
19	805046508	M8×20 10.9 M8×20 BOLT	8
20	805338277	8 WASHER	4
21	310703551	FAN PAD	2
22	310705444	BOARDING	1
