XCMG Counterweight

The XCMG Counterweight is an essential component in XCMG’s machinery, designed to provide stability and balance to heavy – duty equipment. It plays a crucial role in ensuring the safe and efficient operation of various construction and industrial vehicles. This counterweight is a well – engineered product that incorporates a variety of elements to meet the high – performance requirements.

Product Description of XCMG Counterweight

Structural Components
The COUNTER WEIGHT itself is the core of this assembly. It is made of high – density materials to provide the necessary mass for balancing the equipment. There are multiple counterweights used in the system, which are carefully designed and positioned to optimize the overall balance. The BRACKET serves as a support structure for the counterweight and other related components. It is firmly attached to the main body of the equipment, providing a stable foundation for the entire counterweight assembly.
Fastening and Connecting Elements
To ensure that all parts of the counterweight are securely connected, a variety of bolts and screws are used. The M42×160 BOLT and M36×330 BOLT are large – sized bolts that are used to fasten the counterweight to the main structure. They are designed to withstand high – stress loads and ensure a reliable connection. The M10×25 BOLT and M5×30 SCREW are used for smaller components and for fine – tuning the assembly. Washers, such as the 10 WASHER, are placed between the bolts and the components to distribute the load evenly and prevent damage to the surfaces. The WASHER also helps in maintaining the tightness of the bolts over time.
Sealing and Protective Components
PLUGs are used to seal off certain holes or ports in the counterweight. This helps in preventing the entry of dirt, water, and other contaminants, which could potentially damage the internal components. The ANTI – SKID TAPE is applied to the surface of the counterweight. It provides better traction, reducing the risk of slipping during maintenance or when workers are in close proximity to the counterweight.
Auxiliary Components
The MIRROR is an important auxiliary component. It can be used for operators to have a better view of the surrounding area, especially in areas where direct visibility is limited. SPONGE is also included in the assembly. It can be used for shock absorption, noise reduction, or to fill small gaps to prevent rattling. The SPACR (assuming it is a spacer) is used to create the right amount of space between different components, ensuring proper alignment and functionality.

The XCMG Counterweight is a sophisticated and well – thought – out component. With a combination of structural elements, fastening components, sealing and protective elements, and auxiliary parts, it provides reliable balance and stability to XCMG’s machinery. Each part, from the COUNTER WEIGHT to the SPACR, plays a vital role in the overall performance and safety of the equipment.

Product Parameters of XCMG Counterweight

ITEM	PART NO.	PART NAME	Q’TY	IA	REPLACE PART
1	310705405	COUNTER WEIGHT	1	IA	PART NO.	Q’TY
2	310705433	COUNTER WEIGHT	1	I	805339279	0
3	329900391	ANTI-SKID TAPE	3
4	310705435	10 WASHER	2
5	805041950	M42×160 BOLT	2
6	310705413	PLUG	1
7	310705412	PLUG	1
8	805338268	10 WASHER	2
9	805338260	10 WASHER	2
10	805011330	M10×25 BOLT	2
11	310705408	BRACKET	1
12	801968416	MIRROR	1
13	805140364	M5×30 SCREW	1
14	310705407	SPONGE	1
15	310705414	SPONGE	2
16	310600632	SPACR	4
17	310600231	WASHER	4
18	805004799	M36×330 BOLT	4
