Compared to similar models, this machine offers fuel savings of 15–25%, resulting in annual operating cost savings of over 500,000 yuan. It comes standard with a large-capacity 8-cubic-meter rock bucket, delivering powerful performance under heavy-duty conditions and higher loading efficiency. The machine boasts outstanding reliability, with an average operational availability consistently maintained at over 95%. The cab is equipped with a suspension seat and climate control, featuring excellent sealing and a wide field of view.
| Parameter | Value / Description |
|---|---|
| Model | XCMG XE1350G Pro |
| Operating weight | 137,500 kg (approx.) |
| Engine power | 735 kW (985 HP) @ 1800 rpm |
| Engine model | Cummins QSK23 Tier 4 Final / Stage V |
| Bucket capacity (standard) | 7.5 – 10.0 m³ (SAE heaped) |
| Arm digging force | 580 kN |
| Bucket breakout force | 680 kN |
| Hydraulic system pressure | 38 MPa (main) |
| Swing speed | 7.2 rpm |
| Maximum digging depth | 8,250 mm |
| Maximum reach at ground level | 14,150 mm |
| Maximum dumping height | 8,850 mm |
| Fuel tank capacity | 1,650 L |
| Shoe width | 750 mm (triple grouser) |
| Cab noise level | 72 dB(A) |
| Maximum pump flow | 2 x 580 L/min |
| Control system | XCMG Smart Control Pro |
The XE1350G Pro features the XCMG Smart Control Pro system, which electronically adjusts the machine’s parameters based on the workload. This technology delivers fuel savings of up to 18% in ECO mode without sacrificing power. The intelligent cooling system with a variable-speed fan reduces engine consumption and ambient noise. The variable-displacement hydraulic pump responds instantly to the operator’s demands.
The X-Cloud 2.0 monitoring system transmits real-time data on component performance, location, and status. Fleet managers can schedule predictive maintenance and avoid unplanned downtime. The cab features Bluetooth connectivity and USB ports, as well as an air conditioning system with an activated carbon filter that ensures a clean environment even in extremely dusty conditions.
The ROPS/FOPS cab on the G Pro series offers complete protection against rollovers and falling objects. The 360-degree peripheral vision system eliminates blind spots and improves safety in the work area. The operator’s seat features active air suspension and electric lumbar adjustment. Positive cabin pressure prevents dust and particles from entering, protecting the operator’s health during long workdays.
985 HP with electronic control for consistent and efficient performance.
Reduces fuel consumption by up to 18% during moderate workloads.
Recover energy during the downstroke for faster cycling.
Advanced telemetry and remote diagnostics for maximum uptime.
The XE1350G Pro is designed for optimal loading of rigid trucks ranging from 100 to 150 tons. With an 8.5 m³ bucket, it can load a 136-ton truck in just 4 passes. Its 680 kN breakout force allows it to excavate compacted material and soft rock without prior blasting. The long-reach boom facilitates the creation of high, safe stockpiles, optimizing production per work cycle.
For hydraulic breaker applications, the XE1350G Pro comes standard with high-pressure circuits and check valves. The hydraulic system adjusts flow and pressure to maximize impact and protect components. The large-capacity oil cooler maintains optimal temperature even during continuous demolition or ripping work. The versatility of this machine makes it an indispensable asset in any mining operation.
The XE1350G Pro meets the world’s strictest emissions standards thanks to its SCR system with AdBlue and a diesel particulate filter. AdBlue consumption has been optimized to reduce operating costs. The design of the hood and engine mounts minimizes noise emissions, allowing for work in sensitive areas. XCMG has prioritized sustainability without compromising power or productivity.
The XE1350G Pro has one of the lowest total costs of ownership in its class. Engine oil change intervals are extended to 500 hours, and hydraulic oil intervals to 5,000 hours thanks to the advanced filtration system. Lubrication points are centralized at ground level for quick maintenance. XCMG’s global service network ensures immediate availability of genuine replacement parts.
The structural components have been reinforced with high-strength steel and special heat treatments to withstand the harshest conditions. The long-lasting undercarriage reduces wear and extends the machine’s service life. Investing in an XE1350G Pro translates into more tons moved per hour and a lower cost per ton, increasing the long-term profitability of the mining project.
In short, XCMG’s XE1350G Pro mining excavator offers the perfect combination of raw power, advanced electronics, and low operating costs. Its ability to adapt to any mining environment and its mechanical reliability make it the preferred choice of industry leaders. Discover how the XE1350G Pro can transform your mining operation with unprecedented productivity.
XCMG XE1350G Pro — The Future of Mining in Motion
