The XD65TVT is a 5.7-ton combined steel-and-rubber vibratory roller featuring a steel vibrating drum and a static rubber-tired roller. It combines both vibratory compaction and surface finishing functions, making it ideal for small-area compaction tasks as well as renovation and expansion projects in infrastructure construction. The machine is primarily designed for compacting asphalt surface layers on newly constructed roads and for road maintenance, though it can also compact relatively thin stabilized soil layers. With its compact design, agile maneuverability, and minimal blind spots, along with dual-frequency and dual-amplitude vibration, two-speed continuously variable transmission, intermittent water spraying, and dual-control skid steering, it is the ideal compaction equipment for asphalt surface layer compaction in municipal maintenance and highway management.
XCMG XD65TVT Double Drum Vibratory Roller
The XCMG XD65TVT tandem roller is meticulously designed to meet the rigorous demands of contemporary road construction and maintenance projects. With an operating weight of 6,500 kilograms, this machine strikes an ideal balance between maneuverability and compaction force. Its double drum configuration ensures simultaneous compaction of both sides, significantly improving work efficiency on asphalt surfaces, granular bases, and sub-base materials.
Engineered with precision, the XD65TVT features a highly responsive hydraulic system that delivers smooth and consistent vibration across the entire drum width. This results in uniform material density and an exceptionally smooth surface finish. The machine’s advanced drive system provides excellent gradeability and traction, even when operating on challenging inclines or in confined urban work environments where space is limited.
The operator station of the XD65TVT has been thoughtfully designed with ergonomics at the forefront. A spacious platform, intuitive control layout, and excellent all-around visibility reduce operator fatigue during extended work shifts. The vibration-dampened platform absorbs road shocks, ensuring that operators remain comfortable and productive throughout the entire working day. Every control element is positioned within easy reach for maximum operational convenience.
The XD65TVT incorporates a state-of-the-art dual-frequency vibration mechanism that delivers exceptional compaction energy to the working surface. Operators can select between multiple frequency settings to match specific material requirements and project specifications. The high-frequency mode excels at compacting thin asphalt layers, while the lower frequency setting provides deeper penetration for thicker base courses. This versatility makes the machine suitable for diverse job site conditions.
The synchronized vibration system ensures that both drums operate in perfect harmony, eliminating any risk of surface cracking or material displacement. Advanced vibration isolation technology channels energy precisely into the compacted material rather than transmitting it to the machine frame. This design philosophy extends component life and reduces maintenance requirements over the long term.
At the heart of the XD65TVT lies a robust, fuel-efficient diesel engine that meets stringent international emission standards. The powerplant delivers ample torque across a wide RPM range, ensuring consistent performance even under heavy load conditions. Intelligent engine management systems optimize fuel consumption based on real-time operating demands, contributing to lower overall operating costs and reduced environmental impact.
The cooling system has been engineered for extreme operating environments, featuring a high-capacity radiator and efficient airflow design that prevents overheating during prolonged operation in hot climates. Easy-access service points around the engine compartment simplify routine maintenance tasks, reducing machine downtime and keeping your projects on schedule.
The XD65TVT prioritizes operator comfort with a thoughtfully designed workstation that reduces fatigue and enhances productivity. The multi-directional adjustable seat includes lumbar support and vibration dampening, allowing operators of all sizes to find their optimal working position. A clear, unobstructed sightline to both drum edges ensures precise control during edge compaction and when working near curbs or barriers.
An intuitive digital display panel provides real-time feedback on machine parameters including vibration frequency, engine speed, fuel level, and system diagnostics. The centralized control console groups all primary functions within a compact radius, enabling operators to make quick adjustments without interrupting their workflow. All controls are clearly labeled and logically arranged for ease of use.
XCMG has built the XD65TVT using premium-grade materials and components sourced from globally recognized suppliers. The high-strength steel frame provides exceptional structural integrity, resisting torsional stress during demanding compaction operations. Heavy-duty drum bearings and reinforced mounting points ensure reliable performance across thousands of operating hours. The machine is truly built to withstand the rigors of daily construction use.
The pressurized water sprinkler system features corrosion-resistant components and easily cleanable nozzles that deliver consistent drum wetting to prevent asphalt adhesion. A large-capacity water tank extends the interval between refills, allowing uninterrupted operation during extended paving shifts. All hydraulic hoses and electrical wiring are routed through protective channels, shielding them from debris and accidental damage on active job sites.
The versatility of the XD65TVT makes it an invaluable asset across a broad spectrum of construction and civil engineering projects. In highway construction, the machine excels at compacting both binder and surface courses, achieving the specified density requirements with remarkable efficiency. Its consistent performance ensures smooth pavement surfaces that meet rigorous quality standards for major transportation corridors.
Urban road maintenance projects benefit greatly from the XD65TVT’s compact dimensions and excellent maneuverability. The machine navigates narrow city streets and tight intersections with ease, performing patch repairs and overlay compaction without disrupting surrounding traffic flow. Municipal contractors appreciate its ability to deliver high-quality results in confined spaces where larger equipment cannot operate effectively.
Industrial and commercial paving applications represent another key area where the XD65TVT demonstrates its capabilities. From parking lot construction to warehouse floor preparation, the tandem roller produces flat, dense surfaces ready for immediate use. The machine also performs admirably on airport runway and taxiway projects, where surface smoothness and load-bearing capacity are critical safety considerations that must be met with absolute precision.
Investing in the XCMG XD65TVT delivers measurable returns through enhanced productivity and reduced operational expenses. The machine’s ability to achieve target density in fewer passes translates directly into time savings on every project. When calculated over the course of a full construction season, these efficiency gains accumulate into substantial cost advantages that strengthen your competitive position in the marketplace.
Fuel economy is another significant benefit that operators and fleet managers will appreciate. The optimized engine calibration and intelligent power management system consume less fuel per compaction cycle compared to older generation equipment. Over the machine’s service life, these fuel savings represent a considerable reduction in total cost of ownership, freeing up capital for other business investments and growth opportunities.
Reliability stands as a cornerstone of the XD65TVT design philosophy. Every major component has been tested and validated under extreme operating conditions to ensure dependable performance when it matters most. The machine’s robust construction minimizes unscheduled downtime, keeping your projects on track and your clients satisfied with timely completion. This dependability builds trust and strengthens your professional reputation in the construction industry.
XCMG has established itself as one of the world’s foremost construction equipment manufacturers, with a presence spanning over 190 countries and regions. The company’s commitment to research and development is evidenced by its extensive portfolio of patented technologies and continuous product innovations. When you choose the XD65TVT, you are backed by a global support network dedicated to your success and operational continuity.
Quality assurance is integral to every machine that leaves XCMG’s manufacturing facilities. Rigorous testing protocols and strict quality control standards ensure that each XD65TVT meets the same high benchmarks regardless of its destination market. The company’s ISO-certified production processes and use of precision manufacturing equipment guarantee consistency and reliability that contractors can depend on for their most demanding projects.
| Parameter | Specification | Unit |
|---|---|---|
| Operating Weight | 6,500 | kg |
| Front Drum Static Linear Load | 325 / 325 | N/cm |
| Drum Width | 1,700 | mm |
| Drum Diameter | 1,230 | mm |
| Vibration Frequency (High / Low) | 55 / 45 | Hz |
| Nominal Amplitude (High / Low) | 0.8 / 0.4 | mm |
| Centrifugal Force (High / Low) | 80 / 55 | kN |
| Travel Speed Range | 0 – 10 | km/h |
| Maximum Gradeability | 35 | % |
| Engine Rated Power | 56 | kW |
| Engine Rated Speed | 2,200 | rpm |
| Fuel Tank Capacity | 130 | L |
| Water Tank Capacity | 320 | L |
| Overall Length × Width × Height | 4,280 × 1,880 × 3,100 | mm |
| Wheelbase | 2,800 | mm |
| Ground Clearance | 280 | mm |
| Turning Radius (Inner) | 4,500 | mm |
| Steering Mode | Articulated Frame Steering | – |
The XCMG XD65TVT double drum vibratory roller embodies the ideal combination of power, precision, and practicality that modern construction professionals require. Its proven performance across diverse applications, coupled with XCMG’s global reputation for manufacturing excellence, makes this tandem roller a strategic investment for any organization seeking to elevate its compaction capabilities.
From its advanced dual-frequency vibration system to its operator-focused design and robust construction, every aspect of the XD65TVT has been engineered to deliver outstanding results on every project. Whether you are expanding your equipment fleet or replacing aging machinery, this tandem roller offers the performance, efficiency, and reliability needed to succeed in today’s fast-paced construction environment.
