The XD135T vibratory roller meets the requirements of high-end customers and special operating conditions in the domestic market. It is suitable for compacting asphalt pavements and can compact layers of various materials and thicknesses. It is particularly well-suited for pavement compaction in large-scale projects such as roads, parking lots, and airports, and can also be used to compact subgrade and subbase materials. With its wide range of applications, it is the ideal compaction equipment for asphalt surface layer compaction in highway maintenance and construction.
XCMG XD135T Double Drum Vibratory Roller
The XCMG XD135T tandem roller is purpose-built to tackle the most demanding compaction tasks in road construction and heavy civil engineering. With an operating weight of 13,500 kilograms, it delivers immense ground pressure and deep compaction influence, ensuring long-lasting pavement structures. The machine is equally effective on asphalt surface courses, binder layers, and cement-stabilized bases.
Its dual-drum configuration provides symmetric compaction force from both front and rear, eliminating differential density issues often seen with single-drum machines. The high-torque hydraulic drive system, coupled with an articulated center joint, allows smooth steering and a tight turning radius for efficient maneuvering around obstacles and on winding road alignments.
Operator safety and comfort are paramount in the XD135T. The ROPS-certified cabin offers excellent visibility to both drum edges and the surrounding work area. An ergonomic suspension seat, climate control system, and low-vibration platform keep the operator fresh during long shifts. The intuitive digital dashboard provides real-time data on engine status, vibration parameters, and service reminders.
The XD135T features a dual-amplitude, dual-frequency vibration system that adapts to varying material requirements. High amplitude mode delivers deep penetration for thick granular and subbase layers, while low amplitude ensures smooth, non-fracturing compaction on thin asphalt overlays. The centrifugal force reaches industry-leading levels, achieving required density in fewer passes.
An automatic vibration control system synchronizes drum activation with machine travel, preventing over-compaction and surface marks when the roller stops or changes direction. This intelligent feature not only improves quality but also reduces operator workload significantly during precision finishing work.
Under the hood, the XD135T is powered by a turbocharged, electronically controlled diesel engine that meets the latest emission regulations. The engine delivers robust torque at low RPMs, providing excellent fuel efficiency during heavy-load compaction. An advanced cooling package ensures optimal operating temperatures even in high-ambient conditions.
Eco-mode functionality automatically adjusts engine speed to match the current load demand, saving fuel during idle or light-duty travel. This feature alone can reduce fuel consumption by up to 15% over a typical workday, significantly lowering the total cost of ownership for fleet managers and contractors.
The thick, high-grade steel drums are machined to exacting tolerances for perfect roundness and smoothness. A pressurized dual-water sprinkler system with multi-stage filtration ensures uniform coverage across the full drum width, preventing hot asphalt from sticking. The large-capacity water tank supports extended operation between refills.
Scraper bars with adjustable spring tension keep the drum surfaces clean in sticky material conditions. The water nozzles are easily accessible for quick cleaning or replacement, minimizing downtime during routine maintenance. A corrosion-resistant tank and piping extend the service life of the entire sprinkler assembly.
The XD135T cabin has been redesigned with operator feedback in mind. A multi-function LCD display consolidates all critical information in one easy-to-read panel. The joystick control integrates travel direction, speed, and vibration activation, reducing hand movements and improving response time. Excellent sound insulation keeps interior noise levels low.
Large panoramic windows with slim pillars provide outstanding all-round visibility, especially to the drum edges and rear blind spots. The cabin is pre-wired for optional camera systems, further enhancing safety when reversing or working in congested areas. Climate control with efficient air filtration creates a comfortable micro-environment regardless of external dust or temperature.
The XD135T excels in large-scale highway construction, where thick asphalt layers require heavy compaction energy. Its ability to maintain consistent speed and vibration under load ensures uniform density across the entire pavement width, meeting stringent highway authority specifications. The machine’s high productivity makes it ideal for major expressway projects with tight timelines.
Airport runway and taxiway construction demands the highest standards of surface evenness and load-bearing capacity. The XD135T, with its precise dual-drum control and powerful vibration, delivers the smoothness required for aircraft operations. Its reliability under continuous heavy-duty cycles makes it a trusted choice for airfield contractors worldwide.
In industrial and commercial paving, such as logistics centers, container yards, and large parking areas, the roller provides the high static linear load needed to densify thick granular bases. The articulated steering and excellent gradeability allow efficient operation on sloped ramps and uneven terrain, ensuring a solid foundation for heavy traffic.
XCMG is recognized as a top-tier global construction equipment manufacturer, with a strong focus on research and development. The company invests heavily in testing and validation, ensuring that every XD135T roller meets the same rigorous standards regardless of market. A worldwide service network provides parts and technical support whenever and wherever needed.
The XD135T benefits from XCMG’s continuous innovation in compaction technology. The machine is manufactured using precision robotics and assembly processes that guarantee consistent quality and long-term durability. Contractors who choose XCMG gain not only a high-performance machine but also a reliable partner dedicated to their project success.
| Parameter | Specification | Unit |
|---|---|---|
| Operating Weight | 13,500 | kg |
| Static Linear Load (Front / Rear) | 350 / 350 | N/cm |
| Drum Width | 2,130 | mm |
| Drum Diameter | 1,400 | mm |
| Vibration Frequency (High / Low) | 50 / 40 | Hz |
| Nominal Amplitude (High / Low) | 0.9 / 0.45 | mm |
| Centrifugal Force (High / Low) | 180 / 110 | kN |
| Travel Speed | 0 – 8.5 | km/h |
| Maximum Gradeability | 30 | % |
| Engine Rated Power | 119 | kW |
| Engine Rated Speed | 2,200 | rpm |
| Fuel Tank Capacity | 250 | L |
| Water Tank Capacity | 600 | L |
| Overall Dimensions (L × W × H) | 5,450 × 2,300 × 3,200 | mm |
| Wheelbase | 3,600 | mm |
| Minimum Ground Clearance | 350 | mm |
| Turning Radius (Inner) | 5,800 | mm |
| Steering Type | Articulated Hydraulic | – |
The XCMG XD135T double drum vibratory roller is a high-production machine that brings together power, precision, and durability. Its heavy operating weight and advanced vibration technology make it the perfect choice for contractors who demand top performance on large-scale asphalt and base compaction projects. The roller’s fuel efficiency and low maintenance design keep operating costs under control throughout its long service life.
With XCMG’s global reputation for quality and support, the XD135T represents a sound investment for any company looking to upgrade its compaction fleet. From highways to airports, this roller delivers the consistent, high-quality results that modern construction standards require. Explore how the XD135T can elevate your next project to new levels of efficiency and surface quality.
