XCMG QY30K5 Truck Crane

Product Feature Of XCMG QY30K5 Truck Crane

The crane features a specialized boom with an octagonal cross-section, characterized by low dead weight, high strength, and strong lifting capacity.
The use of an advanced concealed boom head, high-strength structural components, and lower sliders with a large contact area enhances load-bearing performance, ensures smoother telescoping movements, and effectively prevents the boom from twisting under lateral loads.
The telescoping mechanism is designed for reliability; specifically, the main telescoping wire rope (which uses anti-rotation wire rope) and the guide pulley bearings are all imported components, ensuring dependable performance.
Structural components are fabricated using superior welding techniques; critical welds are performed by welding robots employing advanced processes, ensuring the reliability of product quality.
Pipe connections utilize ferrule fittings, offering advantages such as reliable connections, excellent sealing, and a low leakage rate.

Description		Unit	Parameter value
Overall length		mm	12570
Overall width		mm	2500
Overall Height		mm	3390
Wheel Base		mm	5025+1350
Track		mm	2074/1834/1834
Total vehicle mass in travel configuration		kg	32400
Axle load	Front axle	kg	7600
	Rear axle		24800
Engine Model			SC8DK280Q3
Engine rated power		kw/(r/min)	206/2200
Engine rated torque		N.m/(r/min)	1112/1400
Max. travel speed		km/h	80
Min. turning diameter		m	22
Min. ground clearance		mm	291
Max. grade ability		%	40
Approach angle		°	19
Departure angle		°	13
Braking distance (at 30 km/h, full load )		m	≤10
Oil consumption per 100km		L	40
Exterior noise level during acceleration traveling		dB (A)	88
Noise level at seated position		dB (A)	90
