XCMG GR5505 Motor Grader

Product Category: Road Machinery
Brand: XCMG
Model: GR5505
Price: $100000.00-$1000000.00 / EA Based On The Features
Delivery Time: 1-90DAYS
Supply Capacity: 1-500UNITS / Year Waiting for Your Order in Stock
Product Origin: China
After-sales Service: Engineers available to service machinery overseas
Rating:
4.9 /5 based on 177 votes

XCMG GR5505

Product Feature

XCMG’s new 550-horsepower GR5505 motor grader, made in China, is a road construction machine.

This motor grader is primarily used for ground leveling, trench excavation, slope grading, bulldozing, soil loosening, snow removal, and other operations in large areas such as highways, airports, and farmland.

It features a friction-disc worm gear reducer with overload protection, specifically designed for heavy-duty mining conditions. The system automatically slips to ensure the safety of both the machine and personnel.
The load-sensing hydraulic system is equipped with a variable-displacement piston pump and a load-sensing multi-way valve to enhance operating comfort; the pilot-operated independent electro-proportional valve, main directional valve, and relief valve are all proportional valves.
The service braking system utilizes a dual-circuit hydraulic braking system.
The machine features an ISO-compliant ROPS & FOPS cab. It is equipped with air conditioning, an adjustable suspension seat, windshield wipers, and defrost vents to enhance operator comfort.
The spacious cab design, combined with a three-dimensional airflow system, provides an excellent driving experience. Optional dual-lever control reduces physical strain by approximately 80%.

Product Parameters

Model			GR5505
Engine	Engine model		QSX15
	Rated power/speed	kw/rpm	399/2100
	Traveling speed forward	km/h	4.7/6.2/9.1/11.9/17.3
	Traveling speed forward	km/h	/22.5/33/42.7
Performance	Traveling speed reverse	km/h	4.7/0.1/17.3/33
	(f=0.75)Tracliveforce	kN	380
	Max.gradeability	%	25
	Min.turning radius using articulation	m	7.3
	Maximum lift above ground	mm	450
Operating specification	Maximum depth of cutting	mm	500
	Maximum blade position angle	°	90
	Blade cutting angle	°	28~70
Blade	Circle reversing rotation	°	360
	Molo board width x height	mm	7300 1607
	Dimension(LxWxH)	mm	1430042004600
	Operating weight(Standard)	kg	63000

Product Applications

This motor grader is primarily used for ground leveling, trenching, slope grading, earthmoving, soil loosening, and snow removal on large-scale sites such as highways, airports, and farmland. It is an indispensable piece of construction equipment in fields such as national defense projects, mining construction, urban and rural road and water conservancy projects, and farmland reclamation.
