XCMG XCA100 Truck Crane

XCMG XCA100

XCMG’s Official 100-Metric-Ton All-Terrain Crane XCA100: Price of China’s New Model of Truck-Mounted Crane.

With powerful performance and exceptional lifting capacity, this four-axle 100-metric-ton all-terrain crane features industry-leading intelligence.

Advantages and Highlights:

All-New, High-Efficiency, Energy-Saving Hydraulic System

Utilizes a closed-loop hydraulic system equipped with a high-displacement pump, enabling extremely fast lifting speeds under heavy loads.

Mature dual-variable mechanisms ensure precise control and stable performance.

Minimum stable hoisting speed (at the drum) of 2.5 meters per minute; minimum stable slewing speed of 0.1° per second.
Intelligent Travel System with Exceptional Off-Road Performance

Industry-first multi-mode drive technology enables real-time intelligent control for various operating conditions, optimizing the crane’s travel performance and enhancing its safety and reliability.

Axle Load Monitoring Technology: This technology automatically selects the appropriate gear (highest gear) and drive mode to ensure safe crane travel.
Power and Travel Performance

MAN diesel engine with a rated power of 319 kilowatts and maximum torque of 2,010 Newton-meters.

Maximum travel speed of 80 kilometers per hour and maximum gradeability of 60%.

Maximum gradeability is 60%, and the minimum turning diameter is 15.8 meters.

Item	Specification		Unit
Overall Length	13180		mm
Overall Width	2750		mm
Overall Height	4000		mm
Wheel Base	2340		mm
Total vehicle mass in travel configuration	48000		kg
Axle Load	12000×4		kg
Engine Model (superstructure)	ISME42030	ISM11E4 440
Engine rated power	306/1900	318/1900	kw/(r/min)
Engine rated torque	2010/1200	2080/1200	N.m/(r/min)
Engine rated torque(chassis)	BF6M1013EC	OM924LA.E3A/1
Engine rated power	174/2300	145/2200	kw/(r/min)
Engine rated torque	854/1400	750/1200-1600	N.m/(r/min)
Max. travel speed	80		km/h
Min. travel speed	3		km/h
Min. turning diameter	18		m
Max. gradeability	60		%
Min. ground clearance	280		mm
Approach angle	17		°
Departure angle	16.5		°
Braking distance (at 30 km/h, full load )	≤10		m
Oil consumption per 100km	60		L
