The XCMG Hydraulic Oil Tank is an indispensable part of XCMG’s hydraulic systems, playing a crucial role in storing and managing hydraulic oil. It is composed of a series of carefully – designed components that ensure its reliable and efficient operation.
In summary, the XCMG Hydraulic Oil Tank is a well – engineered component with a comprehensive set of features. Its combination of storage, filtration, sealing, monitoring, and connection components ensures the proper functioning and longevity of XCMG’s hydraulic systems.
| ITEM | PART NO. | PART NAME | Q’TY |
| 1 | 310705727 | Tank body TANK | 2 |
| 2 | 310705726 | Return flange FLANGE | 7 |
| 3 | 310705725 | Suction flange FLANGE | 1 |
| 4 | 803406072 | Suction filter | 1 |
| 5 | 803406073 | Oil return filter | 1 |
| 6 | 801100123 | O-Ring | 11 |
| 7 | 803073165 | Air filter assembly | 2 |
| 8 | 803173177 | Hydraulic Oil Level Gauge | 9 |
| 9 | 805338261 | Washers | 2 |
| 10 | 805046469 | Bolt M12×25 | 1 |
| 11 | 805338274 | Washer | 1 |
| 12 | 805338263 | Washer | 1 |
| 13 | 805006332 | Bolt M16×40 10.9 (Dacromet) | 1 |
| 14 | 803173220 | Joint | 1 |
| 15 | 803163584 | Joint | 1 |
| 16 | 803166495 | Joint ADAPTER | 1 |
| 17 | 803163572 | Joint | 2 |
| 18 | 803103775 | JOINT ADAPTER | 1 |
| 19 | 803172170 | Plug | 8 |
| 20 | 803173356 | Plug | 1 |
| 21 | 803166490 | Joint | 1 |
