XCMG Chassis Assembly

The XCMG Chassis Assembly represents the pinnacle of engineering prowess, designed to provide robust support and exceptional mobility for heavy – duty machinery. This assembly is a complex integration of various components, each playing a crucial role in its overall performance.

Product Description of XCMG Chassis Assembly

At the heart of the chassis assembly are the track assemblies. Available in different widths such as the Track Assembly 800MM CRAWLER, Track assembly 700MM CRAWLER, and Track Assembly 600MM CRAWLER (also known as Crawler Assembly 600MM CRAWLER and Crawler Assembly 700MM CRAWLER), these tracks offer superior traction and stability on various terrains. They are engineered to withstand heavy loads and harsh working conditions, ensuring reliable operation in the most challenging environments.
Fasteners are essential for holding the entire assembly together. The Bolt M16×45 BOLT, Bolt M18×90, Bolt M18×45 10.9 (Dacromet), Bolt M14×50, Bolt M16×65, Bolt M12×25, and Bolt M10×25 are all precisely designed to provide a secure connection. The 10.9 grade for some bolts indicates high – strength, and the Dacromet coating on washers like Washers 18 300HV (Dacromet), Washer 14 300HV (Dacromet), Washer 16 300HV (Dacromet), Washer 12 300HV (Dacromet) 300HV (Dacromet), and Washer 10 offers excellent corrosion resistance, prolonging the lifespan of the assembly. Nuts such as Nut M14 and Nut M10 work in tandem with the bolts to ensure a tight fit.
The moving parts of the chassis assembly are equally important. The UPPER ROLLER, which appears twice, helps in guiding the track movement smoothly. The GUIDE WHEEL, also in a pair, plays a vital role in maintaining the proper alignment of the tracks. The Tensioner TRACK TENSIONER is responsible for adjusting the tension of the tracks, ensuring optimal performance. The Supporting Wheel LOWER ROLLER, presented in multiple instances, provides support to the track and helps distribute the weight evenly.
The Rail clamp GUARD is used to protect the tracks and other components from debris and damage. The External foot pedal PEDAL offers an interface for operators to control certain functions of the machinery.
The power – transmission components are the TRAVEL MOTOR and the DRIVE GEAR (which appears twice). The TRAVEL MOTOR provides the necessary power for the movement of the chassis, while the DRIVE GEAR transfers the power to the tracks.
Covers and seals are used to protect the internal components. The Motor cover safeguards the travel motor from external elements. The Bottom cover and the Cover help protect the lower parts of the chassis. The Adhesive strip JACKET and SEALING STRIPS are used to prevent dust, water, and other contaminants from entering the assembly. The GREASE DISK COVER helps in maintaining the proper lubrication of moving parts. The RUBBER MAT, presented in a pair, provides insulation and reduces noise and vibration.
Finally, the Lower frame FRAME serves as the foundation of the entire chassis assembly. It provides a stable platform for all the other components and is designed to withstand the stresses and strains of heavy – duty operations.

In conclusion, the XCMG Chassis Assembly is a well – engineered system that combines high – quality components to deliver outstanding performance, reliability, and durability in heavy – machinery applications.

Product Parameters of XCMG Chassis Assembly

ITEM	PART NO.	PART NAME	Q’TY
1	803587291	Refrigerant Hose HOSE	1
2	803587292	Refrigerant tube HOSE	1
3	803587293	Refrigerant pipe HOSE	1
4	822138450	Water hose HOSE	1
5	819951760	Water pipe HOSE	1
6	805046504	Bolt M8×16 10.9 (Dacromet) BOLT	11
7	805338277	Washers 8	11
8	800141502	Gland clamp	2
9	800104574	Hose clamp	4
10	800702258	Pipe fitting JOIN BLOCK	1
11	803704530	LJT01-D145×20 JOIN BLOCK CLAMP	8
12	310706150	Pipe Fitting JOIN BLOCK	1
13	819908628	JOIN BLOCK	1
ITEM	PART NO.	PART NAME	Q’TY
1	803546768	“Compressors”	1
2	80533827	Bolt M8×90	5
3	805046891	Washers 8	4
4	80533826	Washers 8	1
5	80523837	Nut M8	1
6	805046416	Bolt M10×30 10.9 (Dacromet)	3
7	805338279	WASHER 10	3
8	310706148	Compressor bracket	1
9	310901740	Automotive V-belt BELT	1
10	800309026	A Slot tensioning	1
ITEM	PART NO.	PART NAME	Q’TY
1	805046523	“Bolt M8 x 80 10.9 (up to Cro)”	1
2	805238378	Nut M8	2
3	805338259	Washers 8	1
4	805338277	Washers 8	2
5	801905718	AIR FLUE	1
6	803504817	Outside air filter	1
7	803547411	Evaporator assembly	1
8	801905720	AIR FLUE	1
9	801905719	Rear Blowback Corrugated Hose	1
10	800104450	CLAMP	1
11	801905722	Front air transition duct AIR FLUE	2
12	801905721	Transition air duct AIR FLUE	1
13	805139977	Screw M8×35 10.9 (Dacromet) SCREW	7
14	310706331	WASHER	7
15	803547419	Internal air filter FILTER	1
ITEM	PART NO.	PART NAME	Q’TY	IA	REPLACE PART
1	805046497	Bolt M6×25	1	IA	PART NO.	Q’TY
2	805338258	Washers 6	1
3	805338275	Washers 6	1
4	805046416	Bolt M10×30 10.9 (Dacromet)	4
5	805338260	Washer 10	4	I	805339279	0
6	805338268	Washer 10	4
7	310706143	Bracket	1
8	803547413	Condenser	1
9	310706146	Bracket	1
10	805046511	Bolt M8×30	5
11	805338266	Washers 8	4
12	805338259	Washers 8	1
13	805338277	Washers 8	1
