XCMG Air Conditioning System

The XCMG Air Conditioning System is a cutting – edge innovation tailored to meet the demanding cooling requirements of heavy – duty machinery. It combines high – performance components with precision engineering to ensure optimal comfort and efficient operation in various working environments.

Product Description of XCMG Air Conditioning System

Among the core components are the hoses and pipes used for refrigerant and water circulation. The Refrigerant Hose, Refrigerant tube, and Refrigerant pipe are all designed to transport the refrigerant safely and efficiently throughout the system. These HOSE components are made from high – quality materials that can withstand high pressures and extreme temperatures, ensuring the reliability of the cooling process. Similarly, the Water hose and Water pipe are crucial for the water – based cooling functions. They are engineered to resist corrosion and leaks, maintaining a stable water flow for effective heat dissipation.
Fasteners play a vital role in the assembly of the XCMG Air Conditioning System. The Bolt M8×16 10.9 (Dacromet) is a high – strength bolt. The 10.9 grade indicates its excellent tensile strength, while the Dacromet coating provides superior corrosion resistance. This BOLT is used to securely connect different parts of the system, ensuring its structural integrity. The Washers 8 are used in conjunction with the bolts. They help distribute the load evenly, preventing damage to the connected components and enhancing the overall stability of the system.
Clamps are also essential for the proper functioning of the system. The Gland clamp and Hose clamp are used to secure the hoses in place, preventing any refrigerant or water leakage. They provide a tight seal, ensuring that the fluid flow within the system remains uninterrupted.
Pipe fittings are the key to connecting different pipes and hoses in the XCMG Air Conditioning System. The JOIN BLOCK, such as the Pipe Fitting JOIN BLOCK and LJT01 – D145×20 JOIN BLOCK CLAMP, are designed to provide a seamless connection between various components. These JOIN BLOCKs are precision – made to ensure a perfect fit, allowing for smooth and efficient fluid transfer within the system.

In conclusion, the XCMG Air Conditioning System, with its comprehensive range of hoses, pipes, fasteners, clamps, and pipe fittings, offers a reliable and efficient cooling solution for heavy – machinery applications. It is a testament to XCMG’s commitment to quality and innovation in the field of air conditioning technology.

Product Parameters of XCMG Air Conditioning System

ITEM	PART NO.	PART NAME	Q’TY
1	803587291	Refrigerant Hose HOSE	1
2	803587292	Refrigerant tube HOSE	1
3	803587293	Refrigerant pipe HOSE	1
4	822138450	Water hose HOSE	1
5	819951760	Water pipe HOSE	1
6	805046504	Bolt M8×16 10.9 (Dacromet) BOLT	11
7	805338277	Washers 8	11
8	800141502	Gland clamp	2
9	800104574	Hose clamp	4
10	800702258	Pipe fitting JOIN BLOCK	1
11	803704530	LJT01-D145×20 JOIN BLOCK CLAMP	8
12	310706150	Pipe Fitting JOIN BLOCK	1
13	819908628	JOIN BLOCK	1
ITEM	PART NO.	PART NAME	Q’TY
1	803546768	“Compressors”	1
2	80533827	Bolt M8×90	5
3	805046891	Washers 8	4
4	80533826	Washers 8	1
5	80523837	Nut M8	1
6	805046416	Bolt M10×30 10.9 (Dacromet)	3
7	805338279	WASHER 10	3
8	310706148	Compressor bracket	1
9	310901740	Automotive V-belt BELT	1
10	800309026	A Slot tensioning	1
ITEM	PART NO.	PART NAME	Q’TY
1	805046523	“Bolt M8 x 80 10.9 (up to Cro)”	1
2	805238378	Nut M8	2
3	805338259	Washers 8	1
4	805338277	Washers 8	2
5	801905718	AIR FLUE	1
6	803504817	Outside air filter	1
7	803547411	Evaporator assembly	1
8	801905720	AIR FLUE	1
9	801905719	Rear Blowback Corrugated Hose	1
10	800104450	CLAMP	1
11	801905722	Front air transition duct AIR FLUE	2
12	801905721	Transition air duct AIR FLUE	1
13	805139977	Screw M8×35 10.9 (Dacromet) SCREW	7
14	310706331	WASHER	7
15	803547419	Internal air filter FILTER	1
ITEM	PART NO.	PART NAME	Q’TY	IA	REPLACE PART
1	805046497	Bolt M6×25	1	IA	PART NO.	Q’TY
2	805338258	Washers 6	1
3	805338275	Washers 6	1
4	805046416	Bolt M10×30 10.9 (Dacromet)	4
5	805338260	Washer 10	4	I	805339279	0
6	805338268	Washer 10	4
7	310706143	Bracket	1
8	803547413	Condenser	1
9	310706146	Bracket	1
10	805046511	Bolt M8×30	5
11	805338266	Washers 8	4
12	805338259	Washers 8	1
13	805338277	Washers 8	1
