XCMG Center Column

The XCMG Center Column is a sophisticated and robust component designed to enhance the functionality and stability of heavy – duty machinery. Engineered with high – quality materials and advanced manufacturing techniques, it ensures seamless operation and long – lasting durability in demanding industrial environments.

Product Description of XCMG Center Column

Structural Components
At the heart of the XCMG Center Column lies the Slewing shaft SPOOL, which serves as the central axis for rotational movement. This shaft is precision – machined to provide smooth and accurate slewing, enabling the machinery to perform various operations with ease. The Slewing body SHELL encases the slewing shaft, offering robust protection and support. It is constructed to withstand heavy loads and external forces, ensuring the structural integrity of the column.
Sealing and Protection
Sealing is crucial for the optimal performance of the center column. The Rotary Seal and multiple SEAL – RINGs, O – RINGs, along with the Skeleton Dust Ring, work in harmony to prevent the ingress of dust, dirt, and moisture. These seals create a tight barrier, safeguarding the internal components from contaminants that could cause wear and tear. The Wear ring RING further enhances the durability of the column by reducing friction between moving parts, ensuring smooth operation over an extended period.
Fasteners and Additional Components
The End caps COVER are attached to the ends of the center column, providing additional protection and enclosing the internal components. They are secured in place by Hexagon head bolts and Spring washers, which ensure a tight and vibration – resistant connection. The Stopper plate SHIELD adds an extra layer of protection, preventing any accidental movement or displacement of the internal parts. The Cone Plug PLUG is used to seal openings, further enhancing the protection of the column’s internal structure.

In conclusion, the XCMG Center Column is a meticulously designed and highly reliable component. Its combination of sturdy structural components, efficient sealing mechanisms, and robust fasteners makes it an ideal choice for heavy – machinery applications, where performance, durability, and reliability are of utmost importance.

Product Parameters of XCMG Center Column

ITEM	PART NO.	PART NAME	Q’TY
1	860139852	Slewing shaft SPOOL	1
2	860139853	Slewing body SHELL	1
3	860139854	End caps COVER	1
4	860139855	Stopper plate SHIELD	1
5	860139856	Rotary Seal	6
		SEAL-RING
6	860139857	O-RING	1
7	860139858	O-RING	1
8	860139859	Skeleton Dust Ring	1
		SEAL-RING
9	860139860	Wear ring RING	1
10	860139861	O-RING	1
11	860139862	Cone Plug PLUG	4
12	860139863	Hexagon head bolts	4
13	860139864	Spring washers	4
14	860139865	Hexagon head bolts	2
15	860139866	Spring washers	2
