16M articulated mobile elevating work platform aiming to satisfy customers’ requirements. Intelligent and perfect control system features the humanized layout, the maintenance-free design and easy use and maintenance, providing the multiple options and comprehensive safety.
| Item | Unit | Parameter |
| Max. Working Height | m | 15.8 |
| Max. Platform Height | m | 13.8 |
| Max. Working Range | m | 8 |
| Max. Load Capacity | kg | 227 |
| 1st Boom luffing Range | ° | 0～+60 |
| 2nd Boom luffing Range | ° | -8～+75 |
| Fly Jib Luffing Range | ° | -60～+80 |
| Rotation Angle of Turntable | ° | 355 |
| Rotation Angle of Platform | ° | 160 |
| Max. Tail Wagging | mm | 0 |
| Max. Travel Speed | km/h | 5.2 |
| Min. Turning Radius | m | 3.15 |
| Min. Ground Clearance | mm | 210 |
| Max. Grade Ability | % | 30 |
| Tire Specification | – | 250-15 / 240/55D17.5 / 250-15/7.00 |
| Engine Model | – | / |
| Rated Power of Engine | kW/（r/min） | / |
| Battery Specification | V/Ah | 48 /420 （DC） |
| Main Motor Specification | kw/V | 4 /48 （DC） |
| Drive Motor Specification | kw/V | 3.3/32 （AC） |
| Total Weight | kg | 6500 |
| Platform Size | mm | 700×1400×1150 |
| a Overall Length | mm | 6420 |
| b Overall Width | mm | 1750 |
| c Overall Height | mm | 2000 |
| d Wheel Base | mm | 2010 |
| Transportation Width | mm | / |
