XCMG GR3005 Motor Grader

Product Category: Road Machinery
Brand: XCMG
Model: GR3005
Price: $100000.00-$1000000.00 / EA Based On The Features
Delivery Time: 1-90DAYS
Supply Capacity: 1-500UNITS / Year Waiting for Your Order in Stock
Product Origin: China
After-sales Service: Engineers available to service machinery overseas
Rating:
4.9 /5 based on 177 votes

XCMG GR3005

Product Feature

XCMG GR3005 Compact Motor Grader—China’s New Generation of Road Construction Equipment.

This motor grader is primarily used for ground leveling, trenching, slope grading, earthmoving, soil loosening, and snow removal on large-scale sites such as highways, airports, and farmland. It is an indispensable piece of construction machinery in fields such as national defense projects, mining construction, urban and rural road and water conservancy projects, and farmland improvement.

A friction-plate worm gear box with overload protection has been developed specifically for heavy-duty mining conditions. It features automatic slip protection to ensure the safety of both equipment and personnel.
The machine employs a load-sensing hydraulic system equipped with a variable-displacement piston pump and a load-sensing multi-way valve. To enhance operator comfort, the independent pilot electro-proportional valve, main directional control valve, and relief valve all utilize proportional control technology.
The service braking system features a dual-circuit hydraulic brake design.
The cab complies with ISO standards and is equipped with ROPS (Rollover Protection System) and FOPS (Falling Object Protection System) features; it is fitted with air conditioning, an adjustable suspension seat, windshield wipers, and defrost vents, significantly enhancing operator comfort.
The spacious cab features a three-dimensional air duct design, providing an excellent driving experience; an optional dual-lever control mode is available, which can reduce physical strain by approximately 80%.

Product Parameters

Basic parameters	Engine model	QSL8.9-C325-30
	Rated power/speed	242kW/2100rpm
	Overall dimension (standard)	10615x3280x3960
	Total weight (standard)	28000kg
	Tire specification	20.5-25
	Ground clearance (front axle)	450mm
	Space of front and rear axles	7617mm
	Space of middle and rear wheels	1960mm
Performance parameters	Forward velocity	5,8,11,19,23,40km/h
	Reverse speed	5,11,23km/h
	Tractive effort f=0.75	140kN
	Maximum gradeability	30%
	Tire inflation pressure	330kPa
	Working system pressure	22MPa
	Transmission pressure	/
Working parameters	Maximum steering angle of front wheel	±45°
	Maximum slant angle of front wheel	±17°
	Maximum oscillating angle of front axle	±15°
	Maximum oscillating angle of equilibrium box	forwards15°, Reverse15°
	Maximum steering angle of frame	±23°
	Minimum turning radius	9m
Oil filling amount	Coolant	50L
	Fuel tank	480L
	Engine	24L
	Transmission	38L
	Equilibrium box	186L
	Drive alex	106L
	Hydraulic oil	210L

Product Applications

This motor grader is primarily used for ground leveling, trenching, slope grading, earthmoving, soil loosening, and snow removal on large-scale sites such as highways, airports, and farmland. It is an indispensable piece of construction equipment in fields such as national defense projects, mining construction, urban and rural road and water conservancy projects, and farmland reclamation.
