XCMG TY230 Motor Grader

Product Category: Road Machinery
Brand: XCMG
Model: TY230
Price: $100000.00-$1000000.00 / EA Based On The Features
Delivery Time: 1-90DAYS
Supply Capacity: 1-500UNITS / Year Waiting for Your Order in Stock
Product Origin: China
After-sales Service: Engineers available to service machinery overseas
Rating:
4.9 /5 based on 177 votes

XCMG TY230

Product Feature

XCMG TY230 217-horsepower all-new tracked hydraulic bulldozer.The machine features a well-designed layout, outstanding performance, and advanced technology.

The engine offers ample power reserves, high torque output, low fuel consumption, and high reliability.
It employs a hydraulic drive system with automatic and continuously variable transmission capabilities.
The final drive utilizes a triangular spline, tooth-top chamfering, and drum-shaped teeth design, enhancing the load balance and stability of the transmission components.
The new hexahedral cab offers a wide field of view, excellent ventilation, and superior dust protection.

Powerful Performance

The use of a pulsed exhaust manifold optimizes power performance and emission standards.
It offers a large torque reserve and achieves maximum torque at low operating speeds, ensuring strong adaptability.
High-quality cast iron materials and specially designed guide tubes ensure excellent sealing performance and durability.
The crankshaft is robustly designed with high balancing precision.
It incorporates advanced turbocharging and water-cooling technologies.

Product Parameters

Specification/Blade type	Straight-tilt	Angle	U-Blade
Operating Weight(kg)	17400	17700	17900
Min.Ground Clearance(mm)	400	400	400
Min.Tuming Radius(m)	3.2	3.2	3.2
Ground Pressure(MPa)	0.069	0.070	0.071
Track Gauge(mm)	1880	1880	1880
Max.Pulling Force(KN)	142	142	142
Grade Ability(°)	30	30	30
Blade Capacity(m³)	4.5	4.3	8.6
Blade WidthxHeight(mm)	3416×1145	3970×1037	4061×1386
Max.Lift(mm)	1110	1095	1095
Max.Depth(mm)	530	545	545
Max.tilt Adjustment(mm)	≥860	≥400	≥400
Pitch Adjustment(°)	55	55	55
Capability(m³/H)(Theoreticalvalue 40m)	247	247	260
Weight Of Blade(kg)	2350	2450	2560

Product Applications

This motor grader is primarily used for ground leveling, trenching, slope grading, earthmoving, soil loosening, and snow removal on large-scale sites such as highways, airports, and farmland. It is an indispensable piece of construction equipment in fields such as national defense projects, mining construction, urban and rural road and water conservancy projects, and farmland reclamation.
