LW330FN wheel loader, upgraded based on a classical type LW300FN, is a long-wheelbase type with matched and optimized systems and upgraded performances. In addition to all advantages of LW300FN kept, it is characterized with longer wheelbase, bigger steering angle, upgraded hydraulic system, shovel loading capacity and higher operation efficiency. It is more suitable to shoveling and loading materials. It is widely applied to workplaces, such as coal yard, railway, construction area, stone material factory and so on. Thus, it is reliable, efficient and widely used.
Item | Parameters | Unit |
Rated operating load | 3300 | kg |
Bucket capacity | 2.1(1.8~2.5) | m3 |
Machine weight | 10600 | kg |
Dump clearance at maximum lift (ground to main cutting plate) | 2850 | mm |
Reach at maximum lift (front wheel to main cutting plate) | 1080 | mm |
Wheelbase | 2900 | mm |
Tread | 1850 | mm |
Hingeaxle height at lifting limit | 3830 | mm |
Machine height | 3320 | mm |
Maximum traction force | 95 | kN |
Hydraulic cycle time-raise | 5.5 | s |
Total cycling time | 10 | s |
Minimum turning radius (over tire) | 5170 | mm |
Articulation angle | ±38 | ° |
Gradeability | 28 | ° |
Tire specification | 17.5-25-12PR |
|
Overall dimensions (length x width x height) | 7470*2482*3320 | mm |
Engine model | WP6G125E22 |
|
Emission standard | China II |
|
Rated power/rotate speed | 92/2200 | kW/rpm |
Capacity of fuel tank | 185 | L |
Capacity of hydraulic oil tank | 165 | L |
