Description | Unit | lw500kn |
Rated operating load | kg | 5000 |
Bucket capacity | m³ | 2.7~4.5 |
Machine weight | kg | 17200 |
Dump clearance at maximum lift | mm | 3150~3560 |
Reach at maximum lift | mm | 1100~1190 |
Wheel base | mm | 3300 |
Tread | mm | 2250 |
Height of hinge at maximum lift height | mm | 4112 |
Working height(fully lifted) | mm | 5407 |
Max.breakout force | kN | 170 |
Hydraulic cycle time-raise | s | ≤6.5 s |
Total hydraulic cycle time | s | ≤11 s |
Min. turning radius over tyres | mm | 5925 mm |
Articulation angle | ° | 30 º |
Gradeability | ° | 45 º |
Tyre size | 23.5-25-16PR | |
Overall machine dimension L×W×H | mm | 8870*3000*3350 |
Model | WD10G220E21 | |
Rated Power | kW | 162 |
