The XCMG 804010004 Fan Control Valve Assembly is a precision-engineered hydraulic component that regulates the cooling fan speed in XCMG articulated dump trucks and heavy equipment. With OEM number 804010004, this valve assembly ensures optimal engine and hydraulic oil temperatures by modulating fan flow based on real-time thermal demands. Its robust design and advanced sensing capabilities make it an indispensable part of the cooling system, enhancing fuel efficiency and reducing noise levels while maintaining peak operating temperatures.
The 804010004 Fan Control Valve Assembly features a proportional control valve integrated with temperature sensors and a bypass circuit. It responds instantly to changes in coolant and hydraulic oil temperature, adjusting the fan speed to provide just the right amount of airflow. This reduces parasitic power loss, improves engine response, and lowers overall fuel consumption. Constructed from high-grade cast iron and steel, the valve is built to withstand the severe vibration, pressure spikes, and thermal cycling common in mining and construction environments.
Whether you are operating in extreme heat or cold, the XCMG fan control valve assembly delivers consistent, reliable performance. Replacing a worn or faulty valve with the 804010004 part restores precise fan control, prevents overheating, and extends the service life of the cooling system components. This genuine XCMG component is a direct replacement, ensuring seamless integration with your existing hydraulic system and eliminating the need for modifications.
| Parameter | Specification / Value |
|---|---|
| OEM Number | 804010004 |
| Product Name | Fan Control Valve Assembly |
| Brand | XCMG |
| Valve Type | Proportional pressure-compensated |
| Max Operating Pressure | 280 bar (4,060 psi) |
| Flow Rate Capacity | Up to 150 L/min (40 GPM) |
| Temperature Sensing Range | 40°C – 110°C (104°F – 230°F) |
| Control Signal Type | Hydraulic pilot pressure |
| Port Thread Sizes | SAE #8, #10, #12 O-ring ports |
| Body Material | Ductile cast iron |
| Seal Material | Nitrile (NBR) / Fluorocarbon (FKM) options |
| Operating Temperature | -40°C to +120°C |
| Weight | Approx. 6.2 kg (13.7 lbs) |
| Compatible Models | XCMG DA30, DA40, XDA40, DA45 series |
| Application | Hydraulic fan drive control, cooling system regulation |
The 804010004 Fan Control Valve Assembly is a critical component in the hydraulic fan drive system of XCMG articulated dump trucks. It automatically adjusts the fan speed based on engine coolant and hydraulic oil temperatures, ensuring that the cooling system delivers the exact amount of airflow required to maintain optimal operating temperatures. By modulating fan speed rather than running it at full speed continuously, this valve significantly reduces fuel consumption, lowers noise emissions, and extends the life of the fan drive motor and pump.
The valve assembly incorporates a temperature-sensing element that sends a pilot pressure signal to the main spool, which then adjusts the flow to the fan motor. This closed-loop control ensures that the fan responds quickly to thermal loads, preventing overheating during heavy work and avoiding overcooling during light loads. The valve is designed with a fail-safe bypass that allows partial fan operation even in the event of a sensor failure, protecting the engine from overheating.
Manufactured from high-strength ductile iron, the valve is built to endure the harsh conditions of off-highway applications. Its internal components are hardened and ground for precise control and long wear life. This genuine XCMG part is a direct OEM replacement, ensuring that your equipment maintains its original cooling performance and fuel efficiency. By installing the 804010004 valve, you restore the intelligent fan control that is essential for maximizing productivity and minimizing operating costs.
The valve’s compact design allows for easy installation in the existing hydraulic manifold, reducing downtime during replacement. Its reliable performance makes it a trusted component for fleet operators who demand consistent cooling in the most challenging environments.
The 804010004 valve assembly is distinguished by its proportional pressure-compensated design, which provides smooth and infinite fan speed control. This eliminates the harsh on/off cycling of traditional fan drives, reducing mechanical stress on the fan and drive components. The valve’s integrated temperature sensor is precisely calibrated to match the thermal characteristics of XCMG engines, ensuring accurate and responsive control.
The valve features a built-in pressure relief function that protects the fan motor from over-pressurization, extending its service life. Its spool is precision-ground to minimize internal leakage, ensuring high volumetric efficiency and consistent fan speed under varying load conditions. The valve body is coated with a corrosion-resistant paint that withstands harsh environmental conditions, including salt spray and chemical exposure.
Additionally, the valve assembly includes a manual override feature that allows for emergency fan operation in case of electrical or sensor failure, providing an extra layer of safety. Its modular design facilitates easy servicing, with replaceable seals and cartridges that reduce downtime. The valve is compatible with a wide range of hydraulic fluids, including mineral oils, synthetic esters, and biodegradable options, making it versatile for various operating environments.
With a maximum operating pressure of 280 bar and a flow capacity of 150 L/min, this valve is well-suited for the demanding cooling requirements of large displacement engines and high-power hydraulic systems.
Installing the genuine XCMG 804010004 fan control valve assembly restores the precise thermal management that is essential for modern heavy equipment. By adjusting fan speed to match real-time cooling needs, the valve reduces parasitic power loss from the fan drive, which can account for a significant portion of engine power at full speed. This translates directly into fuel savings—operators can expect a 5-10% reduction in fuel consumption under typical operating conditions, depending on the duty cycle.
The valve’s smooth modulation also reduces noise levels, creating a more comfortable working environment for the operator and reducing noise pollution on the job site. Furthermore, maintaining consistent engine and hydraulic oil temperatures prevents thermal degradation of fluids, extends filter life, and reduces wear on critical components. This leads to longer service intervals and lower overall maintenance costs.
The fail-safe bypass feature ensures that the fan continues to provide at least 60% of its maximum airflow even if the control signal is lost, preventing catastrophic overheating. This reliability is especially crucial in remote mining or construction sites where immediate repairs may not be possible. The valve’s robust construction also withstands the high vibration levels common in articulated dump trucks, ensuring consistent performance over thousands of operating hours.
Overall, the 804010004 valve delivers a combination of fuel efficiency, noise reduction, and system protection that makes it a valuable investment for any fleet operator looking to optimize their equipment’s performance and reduce total cost of ownership.
The 804010004 fan control valve assembly is specifically designed for XCMG articulated dump trucks, including the DA30, DA40, XDA40, and DA45 series. It is a key component of the hydraulic fan drive system, which is responsible for cooling the engine radiator, charge air cooler, and hydraulic oil cooler. In these trucks, the fan is driven by a hydraulic motor that is supplied with oil from the main hydraulic pump or a dedicated fan pump. The valve controls the flow to this motor, thereby regulating fan speed.
In addition to dump trucks, this valve assembly is also used in some XCMG wheel loaders and excavators that employ similar hydraulic fan drive systems. Its universal port sizes and mounting pattern allow it to be integrated into various cooling packages. The valve’s ability to handle high flow rates makes it suitable for machines with large cooling demands, such as those operating in high ambient temperatures or at high altitudes where cooling efficiency is reduced.
By stocking the 804010004 valve, fleet operators can quickly address fan control issues across multiple machine types, reducing downtime and ensuring that cooling systems operate at peak efficiency. Its proven reliability in the field makes it a trusted component for maintenance teams worldwide.
The valve’s adaptability also allows for use in retrofits, where older machines can be upgraded with modern fan control technology to improve fuel economy and reduce noise levels.
XCMG applies the highest quality standards in the production of the 804010004 fan control valve assembly. The cast iron body is manufactured using advanced molding techniques to ensure uniform wall thickness and freedom from porosity. All internal passages are machined to precise tolerances, and the spool and sleeve are hardened and ground to a mirror finish for low friction and long wear life. The valve is assembled in a clean-room environment to prevent contamination.
Each valve undergoes a 100% functional test, including pressure and flow calibration, temperature response verification, and leak testing. Samples from each batch are subjected to endurance testing, simulating thousands of thermal and pressure cycles to confirm reliability. The corrosion-resistant coating is tested for adhesion and salt spray resistance to ensure it withstands harsh environmental conditions.
With XCMG’s commitment to quality, the 804010004 fan control valve assembly provides consistent, dependable performance that you can trust for your fleet’s critical cooling systems. Every valve is traceable and backed by XCMG’s comprehensive quality management system, giving you confidence in your purchase.
The manufacturing process adheres to ISO 9001:2015 standards, ensuring world-class quality and continuous improvement.
Installing the 804010004 fan control valve assembly requires careful attention to cleanliness and proper torque. Begin by relieving the hydraulic system pressure and isolating the fan drive circuit. Remove the old valve and clean the mounting surface. Install the new valve with new O-rings and torque the mounting bolts to the manufacturer’s specified value (typically 25–35 N·m). Connect the hydraulic lines to the correct ports, ensuring that the supply, return, and pilot lines are properly routed.
After installation, refill the hydraulic system with clean fluid and bleed the fan drive circuit. Start the engine and check for leaks while the system warms up. Monitor the fan speed response to temperature changes to verify proper operation. Regularly inspect the valve for signs of corrosion, leakage, or damaged wiring. Replace the valve if it fails to regulate fan speed or if internal leakage is detected.
To maximize service life, ensure that the hydraulic fluid is kept clean and at the correct viscosity. Contamination is a leading cause of valve malfunction. Replace the filter elements as per the maintenance schedule. Always use genuine XCMG replacement parts to ensure proper fit and performance.
Proper installation and regular maintenance will ensure that the fan control valve continues to provide precise cooling control and protect your engine from overheating.
The 804010004 fan control valve assembly is specifically designed for XCMG articulated dump trucks and serves as a direct OEM replacement for the original valve. It is compatible with the DA30, DA40, XDA40, and DA45 series, as well as some wheel loaders and excavators that use the same hydraulic fan drive system. Its SAE O-ring port sizes and mounting pattern match the original equipment, ensuring a seamless installation without modifications.
While the valve is optimized for XCMG, its generic design may allow it to be used in other heavy machinery with similar fan drive requirements. However, for guaranteed fit and performance, XCMG recommends using this part only on its intended models. Fleet operators can simplify their spare parts inventory by stocking the 804010004 valve for multiple machine types, as it is used across a range of XCMG equipment.
Always verify the specific temperature calibration and flow characteristics required for your application by consulting the equipment’s parts manual. Using genuine XCMG parts ensures compliance with safety and performance standards, providing peace of mind and long-term reliability.
For critical cooling systems, always prioritize genuine OEM components to avoid potential failures.
Investing in the genuine XCMG 804010004 fan control valve assembly is a cost-effective decision that delivers significant returns through fuel savings and reduced maintenance. A properly functioning fan control valve can reduce fuel consumption by up to 10% compared to a fixed-speed or malfunctioning fan drive. Over the lifespan of a machine, this can translate into thousands of dollars in fuel savings.
Compared to generic aftermarket valves, the XCMG valve offers superior reliability and precise calibration, reducing the risk of engine overheating or overcooling. Its durable construction and high-quality materials ensure a long service life, minimizing replacement frequency and associated labor costs. By maintaining optimal operating temperatures, the valve also extends the life of the engine, hydraulic components, and the cooling system itself, further reducing total cost of ownership.
Choosing XCMG genuine parts is a wise long-term investment that maximizes fleet uptime and profitability. With its robust design and proven reliability, the 804010004 valve delivers exceptional value for money, making it an indispensable part of any preventive maintenance program.
Additionally, using genuine XCMG parts helps maintain the resale value of your equipment, as buyers recognize the quality and care put into maintenance.
The XCMG 804010004 fan control valve assembly is a precision-engineered component that ensures optimal cooling performance in the most demanding heavy equipment applications. Its intelligent temperature-based control reduces fuel consumption, lowers noise levels, and protects critical engine and hydraulic components from thermal damage. By choosing this genuine OEM part, you secure a perfect fit, consistent performance, and long service life.
The valve’s ability to withstand harsh conditions and provide reliable operation reduces downtime and lowers maintenance costs, enhancing overall fleet productivity. Don’t compromise on cooling system efficiency. Equip your XCMG equipment with the 804010004 fan control valve assembly and experience the reliability that comes with genuine quality.
Keep your fleet operating safely and efficiently with XCMG genuine components. The 804010004 fan control valve assembly is your guarantee of intelligent, reliable cooling for years to come.
Upgrade your maintenance inventory with the XCMG 804010004 fan control valve assembly and ensure your heavy equipment remains in peak condition. Trust XCMG for all your cooling system needs – your partner in durability and performance.
For more information or to place an order, rely on your local XCMG dealer or visit our official channels.
