Clamp
Хомут
Abrazadera
The 801974513 Clamp is a genuine XCMG retaining clamp engineered to securely fasten hydraulic hoses, air lines, and electrical conduits in articulated dump trucks and heavy construction equipment. This OEM clamp, identified by part number 801974513, features a robust two‑piece design with a corrosion‑resistant steel band and a durable rubber‑lined inner surface that protects hoses from abrasion and vibration. Designed for quick installation and reliable holding power, the 801974513 clamp ensures that critical fluid and power lines remain properly routed and securely anchored, even under the extreme shock and vibration typical of mining and quarrying operations.
The 801974513 Clamp is a versatile, heavy‑duty retaining clamp that provides secure, vibration‑resistant fastening for hoses, tubes, and cables in XCMG articulated dump trucks.
This genuine OEM clamp is designed to maintain proper routing of hydraulic and pneumatic lines, preventing chafing, kinking, and disconnection that can lead to system failure.
The clamp’s two‑piece construction with a spring‑loaded mechanism allows for quick installation and adjustment without special tools.
A resilient EPDM rubber liner cushions the clamped lines, absorbing vibration and protecting against abrasion from the metal band.
A loose or broken clamp can allow hoses to move excessively, leading to wear and sudden leaks. The 801974513 clamp eliminates these risks with dependable, long‑lasting performance.
In XCMG articulated dump trucks, clamps are used extensively to secure the hundreds of feet of hydraulic hoses, air brake lines, and coolant tubes that run throughout the chassis.
The 801974513 clamp is typically installed on frame rails, axle housings, and engine mounts to hold lines in place, ensuring they do not droop, rub, or become pinched.
Without proper clamping, hoses can vibrate against metal edges, wearing through the outer cover and leading to fluid loss or electrical shorts.
The rubber liner in this clamp also reduces noise transmission and prevents galvanic corrosion between dissimilar metals.
The 801974513 clamp is engineered to withstand the intense vibration and thermal cycling of mining and construction operations, ensuring lines remain securely fastened throughout the equipment’s working life.
The 801974513 clamp features a robust, one‑piece stamped steel body with an integrated spring that maintains constant clamping force even as the hose diameter changes with temperature.
The band is precision‑formed with rolled edges to prevent cutting into the rubber liner or the hose itself.
The EPDM rubber liner is compression‑molded and mechanically retained within the band, ensuring it stays in place during installation and use.
The clamp’s mounting hole is elongated, allowing for some adjustment in positioning to accommodate manufacturing tolerances or routing variations.
The zinc‑plated steel band and stainless steel spring provide excellent corrosion resistance, while the black EPDM liner offers UV and ozone protection.
The 801974513 clamp is manufactured using materials chosen for their durability and compatibility with common automotive and industrial fluids.
The carbon steel band is hot‑dip zinc‑plated to provide a sacrificial layer that protects against rust, even when the clamp is exposed to road salt or moisture.
The EPDM rubber liner is formulated to resist swelling from hydraulic oils, engine coolants, and brake fluids, maintaining its cushioning properties over time.
The spring is made from 304 stainless steel, which offers excellent fatigue resistance and does not corrode, even in high‑humidity environments.
Advanced material science guarantees that the 801974513 clamp delivers reliable clamping force and protection throughout the equipment’s service life.
The 801974513 clamp is used extensively in XCMG articulated dump trucks and other heavy equipment operating in surface mining, underground mining, and large‑scale construction.
It is commonly installed to secure hydraulic hoses along the chassis frame, air brake tubing on the axle, and coolant lines on the engine.
The clamp is also used to bundle electrical harnesses, keeping them tidy and protected from mechanical damage.
In dusty and muddy environments, the clamp’s robust design prevents debris from accumulating and causing chafing.
The 801974513 clamp is also suitable for other XCMG equipment, including wheel loaders and motor graders that use similar line routing configurations.
Every 801974513 clamp is manufactured in an ISO 9001‑certified facility under strict quality control procedures.
Raw steel and rubber materials are sourced from approved suppliers and tested for composition, hardness, and tensile strength.
During stamping and assembly, each clamp is inspected for dimensional accuracy, spring force, and liner retention.
Finished clamps are subjected to salt‑spray testing per ISO 9227 to verify corrosion resistance, and pull‑testing to confirm clamping force.
This comprehensive quality assurance programme guarantees that every 801974513 clamp meets XCMG’s rigorous standards for reliability and safety.
The 801974513 clamp is designed as a direct replacement for the original clamp on XCMG articulated dump trucks, including models XDA30, XDA40, XDA45, XDA45U, XDA60, TA30, AD45, AD60, and others.
Its clamping range of 20 – 35 mm covers the most common hose and tube diameters used in these machines.
The M8 mounting hole accepts standard bolts or screws, fitting existing threaded bosses or through‑holes on the chassis.
For cross‑brand applications, verify that the bundle diameter falls within the clamp’s range and that the mounting method is compatible.
Always consult the parts manual to confirm the correct clamp for your specific routing application.
Proper installation of the 801974513 clamp is simple. Open the clamp by pressing the spring tabs, then place it around the hose or cable bundle at the desired location.
Ensure that the rubber liner fully covers the contact area and that the clamp is oriented so that the mounting hole aligns with the support bracket.
Insert the M8 bolt through the mounting hole and tighten to 15–20 N·m, using a washer and nut if required.
The spring tension will automatically adjust to the diameter, but do not over‑compress the clamp, as this may damage the liner.
During routine maintenance, visually inspect the clamp for signs of rubber deterioration, corrosion, or loosening. Re‑tighten if necessary.
If the rubber liner becomes cracked or hardened, replace the clamp to maintain protection of the lines.
The 801974513 clamp complies with SAE J1508, which specifies performance requirements for hose clamps used in automotive and off‑highway applications.
It also meets the material restrictions of RoHS, ensuring that the clamp is free from hazardous substances.
The EPDM rubber is formulated without phthalates or heavy metals, making it safe for operators and environmentally responsible.
Using genuine XCMG clamps like the 801974513 helps maintain compliance with equipment warranty and safety regulations.
Aftermarket clamps may look similar, but they often use inferior rubber compounds, thinner steel, or weaker springs that lead to early failure.
The genuine 801974513 clamp is engineered specifically for XCMG equipment, ensuring proper fit, consistent clamping force, and long‑term protection.
Using genuine clamps reduces the risk of hose chafing, premature wear, and costly fluid leaks.
Genuine XCMG parts also preserve the warranty and resale value of your equipment.
When you choose the 801974513, you invest in proven reliability and long‑term cost savings.
The XCMG 801974513 Clamp is a vital component for protecting and securing hydraulic, pneumatic, and electrical lines in articulated dump trucks and heavy machinery.
Its durable steel band, resilient EPDM liner, and robust spring mechanism provide reliable holding power and vibration damping, extending the life of critical lines.
Whether you are performing routine maintenance, re‑routing lines, or building a new machine, this genuine clamp delivers the performance and reliability you expect from XCMG.
Always source genuine XCMG components from authorised dealers to guarantee authenticity and quality.
With the 801974513 clamp, you can protect your equipment from unexpected failures, reduce downtime, and ensure safe operation.
Choose genuine – choose XCMG for all your hose and cable management needs.
