The genuine XCMG Bracket with OEM number 800172536 is a heavy‑duty structural mounting component engineered for XCMG articulated dump trucks, wheel loaders, and mining equipment. Manufactured from high‑strength alloy steel with precision CNC machining and robotic welding, this bracket provides rigid support for engine ancillaries, hydraulic valve blocks, and chassis attachments, ensuring vibration‑free alignment and long‑term durability under extreme dynamic loads and off‑road conditions.
The XCMG Bracket 800172536 is manufactured using high‑strength, low‑alloy steel (Q355D), which offers excellent weldability and impact resistance down to -40°C. The bracket is laser‑cut and CNC‑formed to ensure perfect dimensional accuracy. All critical weld seams are robotically welded and 100% inspected using magnetic particle testing (MT), guaranteeing zero porosity or cracking.
The design incorporates multiple gussets and ribbed reinforcements at high‑stress zones, achieving a safety factor of 4.8 against static loads. FEA analysis confirms that the bracket can withstand 5 million vibration cycles at 30 Hz without any structural degradation. This robustness is essential for articulated dump trucks that operate continuously on rough haul roads.
OEM 800172536 is the factory‑specified bracket for mounting the air compressor, power steering pump, and hydraulic tank on AD45, AD60, and AD80 articulated trucks. The bolt hole pattern matches the original engine block and chassis within 0.2mm, eliminating the need for reaming or shimming. The bracket includes captive nuts and alignment dowels to simplify installation and guarantee perfect belt alignment for accessory drives.
When replacing a cracked or corroded bracket, using genuine 800172536 restores original component alignment and prevents premature belt wear. Aftermarket brackets often use thinner steel (6‑8mm vs. genuine 10mm) and lack proper weld penetration, leading to cracking within 2,000 hours. Protect your engine ancillaries with an OEM‑grade foundation.
The bracket features integrated rubber‑metal isolator bushings (pre‑installed) that reduce high‑frequency vibration transmission to mounted accessories. Independent lab tests show a 42% reduction in peak acceleration compared to rigid brackets. This extends the service life of alternators, compressors, and drive belts by up to 30%.
The three‑layer corrosion protection system – zinc phosphate conversion coating, electrodeposited epoxy (e‑coat), and polyester powder topcoat – provides exceptional chip resistance and salt spray protection (800+ hours). This makes the bracket ideal for coastal mines, winter road salt applications, and high‑humidity environments.
A 24‑month study on 25 XCMG AD60 dump trucks in a South African platinum mine compared genuine Bracket 800172536 against aftermarket alternatives. The genuine brackets showed zero cracks or loosening after 10,000 operating hours, while aftermarket brackets failed at an average of 2,400 hours due to weld seam fatigue and material corrosion.
The mine reported a 78% reduction in accessory drive failures and an annual saving of $88,000 in labor and parts. Additionally, the elimination of bracket cracks prevented two catastrophic incidents where a loose air compressor caused belt shredding and coolant hose damage. The genuine brackets continue to perform reliably after 16,000 hours.
Replacing a bracket with OEM 800172536 typically takes 60–90 minutes. Support the engine accessory with a hydraulic jack. Clean all mounting surfaces, apply medium‑strength threadlocker (Loctite 243) to bolts, and torque chassis bolts to 120 Nm (M16 grade 10.9) and accessory bolts to 60 Nm (M14). Use the new rubber isolators provided – never reuse old ones.
After installation, check belt alignment with a laser tool and adjust tension to spec. Re‑torque all bolts after 50 operating hours due to initial settling. Inspect bracket welds during every engine oil change (500 hours). If any crack or coating damage exposing bare metal is found, replace immediately. Proper torque and alignment are critical for maximum service life.
All XCMG genuine brackets, including 800172536, are produced in IATF 16949 and ISO 9001:2015 certified facilities. Each bracket is serialized and receives a dimensional conformity report and weld inspection certificate. The product is covered by a 24‑month warranty against manufacturing defects (excluding impact damage or improper installation).
Using genuine XCMG brackets preserves your machine’s warranty and ensures compliance with factory safety standards. Counterfeit brackets often use sub‑standard steel with inadequate weld strength, leading to sudden failure and potential injury. Protect your crew and your investment – always insist on authentic OEM 800172536 from authorized XCMG distributors.
