The genuine XCMG Engine Oil Filter with OEM number 800167625 is a high-efficiency spin-on filter designed for XCMG articulated dump trucks, wheel loaders, and heavy off-highway equipment powered by Cummins, Deutz, or XCMG diesel engines. This filter removes abrasive particles, soot, and sludge from engine oil, ensuring clean lubrication for turbochargers, bearings, and piston rings. The 800167625 oil filter features a multi-layer synthetic media, high dirt-holding capacity, and a robust steel canister, delivering reliable protection for up to 500 hours of operation in severe mining conditions.
The XCMG Engine Oil Filter 800167625 is engineered to provide exceptional particle removal while maintaining high flow rates essential for modern turbocharged diesel engines. Its synthetic fiber media captures abrasive contaminants as small as 15 microns, preventing premature wear of camshafts, crankshaft bearings, and piston rings. The high dirt-holding capacity of 35 grams extends filter service life even in high-soot mining conditions.
On AD60 and AD80 articulated dump trucks, this filter is the direct OEM replacement for the original equipment spin-on filter. Field data from Australian mines show that using genuine XCMG 800167625 filters reduces engine overhaul frequency by 25% compared to aftermarket alternatives, thanks to superior contamination control.
The 800167625 filter uses a multi-layer synthetic fiber matrix reinforced with micro-glass fibers. This design achieves a beta ratio of β15=200 (99.5% efficiency at 15 microns) while maintaining low flow restriction. The media is resin-impregnated for high wet-strength and resistance to oil degradation, ensuring consistent filtration performance over the entire service interval.
Unlike cellulose-based filters, the synthetic media does not swell or collapse when exposed to moisture, acids, or high soot loads. This is critical in mining environments where condensation can occur inside the crankcase. The media also provides excellent cold-flow characteristics, allowing oil to reach critical components quickly during startup at -40°C.
The filter housing is made from heavy-gauge, cold-rolled steel with an E-coat finish that resists rust and corrosion even in high-humidity or salt-spray environments. A high-strength bypass valve is set to open at 2.5 bar differential pressure, ensuring oil flow to the engine even if the filter becomes clogged. This prevents oil starvation while alerting the operator to service the filter.
The anti-drain back valve (silicone membrane) prevents oil from draining out of the filter when the engine is off, eliminating dry starts and reducing wear. The sealing O-ring is pre-lubricated to simplify installation and prevent leaks. Each filter is pressure-tested to 2.0 MPa and burst-tested to over 4.0 MPa, far exceeding industry standards.
To replace the engine oil filter, run the engine until warm, then shut down and drain the oil. Place an oil catch pan under the filter. Using a strap wrench, loosen and remove the old filter by turning counterclockwise. Clean the filter mounting base thoroughly, removing any old gasket residue. Apply a thin film of clean engine oil to the new filter’s gasket.
Screw the new XCMG 800167625 filter onto the mounting stud until the gasket contacts the base, then tighten an additional 3/4 to 1 turn (approx. 25 Nm). Do not over-torque. Refill with the correct grade of engine oil (XCMG recommends 15W-40 for most ADT applications). Start the engine and check for leaks. Allow the oil pressure light to go out, then re-check the oil level and top up if necessary.
Change the oil filter every 500 hours or every second oil change, whichever comes first. In severe conditions (high dust, extended idle, high soot loads), reduce interval to 250 hours. Always record the filter change in the equipment logbook. Dispose of used filters according to local environmental regulations.
Counterfeit oil filters sold as 800167625 often use poor-quality cellulose media, low-strength canisters, and incorrect bypass valve settings. Symptoms include filter collapse (restricted oil flow), media degradation (contaminants passing through), and external leaks. Genuine XCMG filters have a laser-etched part number on the canister, a holographic label on the box, and a specific canister crimp pattern.
Another common issue is missing or defective anti-drain back valves, leading to dry starts and increased engine wear. Genuine XCMG filters have a visible orange silicone valve that remains flexible at all temperatures. Counterfeit valves may be black rubber that hardens and leaks. Always inspect the filter before installation – a genuine filter has a clean, uniform paint finish and the bypass valve is firmly seated.
Thread mismatch: Some aftermarket filters have the same external dimensions but an incorrect thread pitch (e.g., M20 instead of M24), causing improper sealing or filter loosening. The genuine 800167625 uses a precise M24×1.5 thread. Always verify thread compatibility before installation.
A high-quality oil filter is the most cost-effective way to extend engine life. Using a genuine XCMG 800167625 filter reduces abrasive wear by up to 80% compared to a low-efficiency aftermarket filter. This translates to extended bearing and ring life, fewer overhauls, and lower total cost of ownership.
Fleet studies show that trucks using genuine XCMG oil filters achieve 15% longer oil drain intervals (when supported by oil analysis) and 30% lower engine wear metal levels. Predictive maintenance: Combine filter changes with regular oil sampling. If soot or silicon levels rise prematurely, the filter may be reaching its limit or the engine air intake may be leaking.
Payback analysis: A genuine XCMG 800167625 filter costs approximately $18. A counterfeit filter costing $12 may save $6 upfront, but if it fails and causes a turbocharger failure ($2,500) or engine bearing damage ($8,000+), the savings are meaningless. Over the life of an AD60, using genuine filters reduces total operating costs by thousands of dollars.
Every XCMG Engine Oil Filter 800167625 is manufactured in an IATF 16949-certified facility. Each filter undergoes 100% leak testing, burst pressure testing, and media integrity testing (bubble point). Random samples are tested for filtration efficiency (ISO 16889), dirt holding capacity (ISO 4548-12), and vibration resistance. XCMG provides a 24-month warranty against manufacturing defects.
Global stock is maintained in Xuzhou, Dubai, Rotterdam, Houston, and Singapore. Emergency orders ship within 24 hours. Bulk packs of 12 filters (part number 800167625-B12) are available for fleet customers, offering a 15% discount. Each filter is individually sealed in a shrink-wrapped bag with a moisture-absorbing packet.
To verify authenticity, scan the QR code on the box – it links to a certificate showing the filter’s batch number, production date, and test results. Always insist on genuine XCMG 800167625; counterfeit filters have been known to collapse, causing catastrophic engine failure.
XCMG tested the 800167625 oil filter under extreme conditions: -45°C cold start (Heihe, China), +55°C ambient with high dust (Australian mines), and 10,000 hours of field operation. The filter maintained structural integrity and filtration efficiency throughout. The synthetic media did not collapse or lose efficiency even after 500 hours of operation with 3% soot loading.
For extremely dusty environments (coal mines, desert operations), XCMG recommends adding a secondary filter (part 800167625-EXT) that mounts upstream of the main filter, doubling the dirt-holding capacity. This extended-life kit is especially beneficial for trucks operating in severe dust conditions.
Vibration and shock: The filter passed 200 hours of random vibration at 20g RMS (simulating severe haul roads). No internal component damage or thread loosening occurred. The E-coat finish resisted chipping and corrosion even after 1,000 hours of salt spray testing.
