Spring Assembly
Пружина в сборе
Conjunto de resorte
The 318502912 Spring Assembly is a precision-engineered cushioning and tensioning component designed for XCMG hydraulic excavators. As a critical non-engine auxiliary part, this spring assembly provides controlled force absorption and return action in applications such as travel motor parking brakes, swing brake mechanisms, and valve actuators. Manufactured from high-grade spring steel with a durable corrosion-resistant coating, the 318502912 spring assembly guarantees consistent force characteristics, long fatigue life, and reliable performance in the most demanding construction and mining environments.
The 318502912 Spring Assembly is a precision-engineered component that provides controlled force and energy absorption in XCMG hydraulic excavators. As a non-engine auxiliary part, this assembly is used in critical systems such as travel motor parking brakes, swing brake mechanisms, and control valve return applications. Its primary function is to store and release mechanical energy, ensuring smooth engagement and disengagement of moving parts, thereby enhancing machine safety and operational precision.
Constructed from high-grade chrome-vanadium steel (SAE 6150), the 318502912 spring assembly offers excellent fatigue resistance, high tensile strength, and resilience. The spring is heat-treated and shot-peened to enhance its durability and extend its service life. The assembly includes precision-machined guides and seats that ensure proper spring alignment and prevent buckling under load, maintaining consistent force characteristics throughout its operating cycle.
The 318502912 Spring Assembly features a precisely wound coil with a wire diameter of 8 mm and an outer diameter of 50 mm, providing a spring rate of 25 N/mm. This ensures consistent force output and reliable actuation in brake and valve applications. The assembly’s free length of 120 mm and solid length of 45 mm allow for adequate stroke, accommodating various travel requirements without reaching coil bind.
The phosphate coating with oil finish provides excellent corrosion resistance and reduces friction between the spring coils, minimizing wear and extending service life. The spring’s working load of 1200 N at 80 mm length ensures sufficient force for braking and valve return functions, contributing to machine safety and responsiveness. The included guides prevent lateral movement, ensuring consistent performance even under heavy vibration and shock loads.
By using the genuine 318502912 spring assembly, operators can maintain the original performance and reliability of their XCMG excavators. Its direct OEM fitment eliminates the need for modifications, reducing installation time and ensuring proper function. This component is essential for maintaining safe and efficient machine operation.
The 318502912 Spring Assembly is specifically designed for use in XCMG hydraulic excavators, including popular models such as the XE210, XE240, XE305, and other XE series machines. It is commonly employed in the travel motor parking brake system, where it applies spring force to hold the brake engaged when hydraulic pressure is released. It is also used in swing brake assemblies and pilot control valve returns.
This spring assembly is suitable for a wide range of heavy equipment applications beyond excavators, including wheel loaders, crawler cranes, and drilling rigs that utilize similar spring-based actuation systems. Its robust construction and consistent force characteristics make it ideal for demanding environments where equipment is subjected to continuous operation, heavy loads, and extreme temperatures.
When replacing a worn or broken spring assembly, using the genuine 318502912 part ensures proper fit, material quality, and performance. Aftermarket alternatives may not provide the same force characteristics or fatigue life, potentially leading to brake failure or valve malfunction.
Installing the 318502912 Spring Assembly requires mechanical expertise and attention to safety. Before installation, ensure the hydraulic system is depressurized and the machine is securely supported. Remove the old spring assembly and inspect the housing and mating components for wear or damage.
Clean the mounting surfaces and apply a thin layer of grease to the spring guides to ensure smooth operation. Position the new spring assembly in the housing, ensuring it is correctly oriented with the guides and seats. Compress the spring using appropriate tools and secure the retaining hardware to the specified torque.
After installation, operate the system through its full range of motion to verify proper spring function. Check for any binding, unusual noise, or insufficient travel. Regular inspection of the spring assembly is recommended as part of routine maintenance. Replace the assembly if any signs of corrosion, deformation, or fatigue cracks are observed.
The 318502912 Spring Assembly is manufactured in ISO 9001 certified facilities under strict quality control. The chrome-vanadium steel is sourced from approved suppliers and undergoes chemical analysis and mechanical testing to verify its properties. Each spring is formed, heat-treated, and shot-peened to achieve optimal residual stress and fatigue life.
The spring is tested for free length, solid length, and spring rate using precision measurement equipment. The assembly is subjected to cyclic load testing to ensure it meets the specified fatigue life requirements. The phosphate coating is inspected for uniformity and adhesion, and salt spray testing confirms corrosion resistance.
Using genuine XCMG 318502912 spring assemblies ensures proper fit, performance, and reliability. Counterfeit or aftermarket springs may not provide the same force characteristics or fatigue life, potentially leading to premature failure and safety hazards. Always source genuine parts from authorized distributors.
The 318502912 Spring Assembly is a vital component for maintaining the safety and performance of XCMG hydraulic excavators. As a non-engine auxiliary part, it provides reliable force control for braking and valve actuation, ensuring precise machine operation and operator safety.
With its high-quality steel construction, precise engineering, and exact OEM fitment, this spring assembly offers exceptional durability and consistent performance. Choosing the genuine 318502912 assembly protects your equipment from failures and reduces maintenance costs. Always source this part from authorized XCMG distributors to guarantee authenticity and full compliance with specifications.
Whether for planned maintenance or emergency repairs, the 318502912 spring assembly is the trusted choice of professionals who demand quality, reliability, and performance from every component in their heavy equipment.
