XCMG Wheel Loaders Heater With Warm Air System

Introduction to Heater With Warm Air System
The XCMG Wheel Loaders Heater With Warm Air System is a specialized climate control solution designed to provide consistent warmth in freezing conditions, ensuring operator comfort and optimal machine performance. Engineered to integrate seamlessly with the loader’s hydraulic and cooling systems, this assembly delivers reliable heat output while prioritizing energy efficiency and durability in harsh, low-temperature worksites.

Product Description of XCMG Wheel Loaders Heater With Warm Air System

Core Heating Components
At the heart of the system is the Plumbing Heater, a robust heat exchanger that utilizes engine coolant to generate warm air. It connects to the loader’s cooling circuit via Water Inlet Hose and Water Return Hose, which channel hot coolant through the heater core. The Heater Connector and Water Temperature Connector ensure precise integration with the machine’s temperature control system, allowing operators to adjust output based on environmental needs.
Fluid Management and Connections
A network of Water Pipes, secured with Double Wire Ferrule 22 to 26, maintains safe coolant flow while resisting pressure and temperature fluctuations. The Shut-off Valve controls coolant flow to the heater, enabling seasonal adjustments or maintenance shutdowns, while the Drain Valve facilitates easy fluid evacuation during servicing. These components are fastened using Bolt M6X25 and dual Washer 6, ensuring leak-proof connections even under vibration.
Mounting and Structural Stability
The heater assembly is rigidly mounted using Bolt M8X30, Nut M8, and Washer 8 pairs, which secure the unit to the loader’s frame or cab structure. This configuration minimizes movement and noise, while the corrosion-resistant finish on metal components protects against rust in wet or salty environments. The Connector points are designed for quick installation, reducing downtime during system integration or repairs.
Operational Control and Safety
The Water Temperature Connector communicates with the loader’s dashboard display, providing real-time feedback on coolant temperature and heater performance. This allows operators to monitor system efficiency and detect issues early. The inclusion of a pressure-rated Shut-off Valve adds a layer of safety, preventing accidental coolant leaks and ensuring the system operates within manufacturer specifications.
Engineering Excellence for Cold-Climate Performance
XCMG’s heater system undergoes rigorous testing to validate its performance in sub-zero temperatures. The plumbing heater’s aluminum core offers excellent thermal conductivity, while the double-wire ferrules and reinforced hoses resist cracking in extreme cold. The modular design of components like the Drain Valve and Water Inlet/Return Hoses simplifies maintenance, allowing technicians to replace parts quickly without extensive disassembly.
Conclusion: Reliable Warmth for Productive Operations
The XCMG Wheel Loaders Heater With Warm Air System is a critical asset for operations in frigid environments, delivering consistent heat to keep operators comfortable and machinery functioning optimally. By integrating durable components, precise fluid management, and user-friendly controls, XCMG ensures this system withstands the harshest cold-weather challenges—maximizing productivity while prioritizing safety and ease of use.

Product Parameters of XCMG Wheel Loaders Heater With Warm Air System

Sr.No.	Part No.	Description	Q’ty	Remark
1	5005125	Plumbing heater	1
2	4A05003	Double wire ferrule 22 to 26	8	JB3616.1-1984
3	9349247	Water pipe	2
4	4005031	Bolt M6X25	4	GB5783-86
5	4401006	Washer 6	1	GB93-87
6	4404007	Washer 6	4	GB97.1-85
7	4401007	Washer 8	2	GB93-87
8	4404008	Washer 8	2	GB97.1-85
9	4005042	Bolt M8X30	2	GB5783-86
10	4301008	Nut M8	2	GB6170-86
11	9349246	Heater connector	1
12	5000551	Drain valve	2
13	9366011	Water inlet hose	1
14	9366012	Water return hose	1
15	9302347	Connector	1
16		Shut-off valve	1	Heater belt
17	9309930	Water temperature connector	1
