XCMG Wheel Loaders Hydraulic Oil Tank

XCMG Wheel Loaders Hydraulic Oil Tank: Reliable Fluid Management for Heavy-Duty Hydraulics
Introduction
The XCMG Wheel Loaders Hydraulic Oil Tank is a critical component designed to store, filter, and regulate hydraulic fluid, ensuring optimal performance and longevity of the loader’s hydraulic system. Engineered for durability and efficiency, this tank integrates robust materials and precision components to withstand harsh worksite conditions while maintaining clean, stable fluid supply for seamless operation.

Product Description of XCMG Wheel Loaders Hydraulic Oil Tank

Core Structural Components
The Tank, constructed from high-grade steel or lightweight aluminum alloy, forms the primary reservoir for hydraulic oil. It features a reinforced Flange Joint at the top, secured by Bolts, Washers, and Lock Washers to create a leak-proof seal with the Cover. The cover houses a primary Filter, which traps contaminants during fluid intake, while a secondary Oil Filter (internally mounted) provides additional filtration to prevent wear on pumps and valves.
Fluid Monitoring and Maintenance
A Level Gauge is strategically positioned on the tank for easy visual inspection of oil levels, ensuring operators can maintain optimal fluid volume. The gauge is attached with Bolts and Washers, resistant to vibrations that could affect accuracy. A Plug at the tank’s base allows for quick drainage during maintenance, paired with a magnetic insert to capture metallic debris, enhancing fluid cleanliness.
Sealing and Connectivity
Critical joints, such as the interface between the tank and hydraulic lines, are sealed with O-rings and reinforced by Flange Joints, ensuring airtight connections and preventing moisture ingress. Clamps and Hoses secure fluid pathways, with Joints fitted with Washers and Lock Washers to withstand pressure fluctuations. The tank’s design minimizes turbulence, reducing foam formation and improving heat dissipation for consistent fluid viscosity.
Engineering for Durability
The tank’s internal surface is coated with anti-corrosive materials to resist degradation from hydraulic fluid additives or environmental moisture. External components, including Bolts and Lock Washers, are made from stainless steel to prevent rust, even in humid or salt-laden environments. The modular design of filters and covers allows for quick replacement, minimizing downtime during routine servicing.
Operational Efficiency Features
By integrating dual-stage filtration (primary and secondary Filters), the tank ensures hydraulic oil remains free of particulates, extending the life of pumps, valves, and cylinders. The Level Gauge and easy-access drain plug streamline maintenance, while the robust structural design supports stable fluid supply under heavy loads or rapid maneuvers.
Conclusion: Essential for Hydraulic System Longevity
The XCMG Wheel Loaders Hydraulic Oil Tank delivers unmatched reliability in fluid management, combining durable construction, advanced filtration, and user-friendly maintenance features. Ideal for construction, mining, and industrial applications, this tank ensures the hydraulic system operates at peak efficiency, reducing wear, minimizing downtime, and enhancing overall machine productivity. Trust XCMG’s engineering excellence to keep your equipment performing reliably, even in the toughest environments.

Product Parameters of XCMG Wheel Loaders Hydraulic Oil Tank

Sr.No.	Part No.	Description	Q’ty	Remark
1	9364953	Tank	1
2	9306446	Filter	1
3	9319530	Washer	1
4	9304025	Flange	1
5	4401008	Lock Washer	22	GB93-87
6	4005053	Bolt	18	GB5783-86
7	4401006	Lock Washer	12	GB93-87
8	4005313	Bolt	6	GB5783-86
9	4829002	Washer	1	JB1102-77
10	4614004	Plug	1	JB1000-77
11	9309184	Cover	1
12	9309192	Filter	1
13	9309170	Washer	1
14	4005040	Bolt	4	GB5783-86
15	4401007	Washer	1	GB93-87
16	9318068	Cover	1
17	9318071	Washer	1
18	5002151	Oil Filter	1
19	5000093	Level Gauge	1
20	9309188	Joint	1
21	4005032	Bolt	6	GB5783-86
22	4401006	Washer	12	GB93-87
23	9364957	Flange Joint	1
24	4827045	O-ring	1	GB3452.1-1992
25	4829008	Washer	1	Q/SC1294-2000
26	9349342	Joint	1
27	4A05024	Clamp	1	JB3616.1-1984
28	9349798	Hose	1
29	4213004	Bolt	2	GB825-88
