XCMG Wheel Loaders Floor Assembly

Introduction to Floor Assembly
The XCMG Wheel Loaders Floor Assembly is a critical structural component designed to integrate operator controls, enhance comfort, and ensure safety during heavy-duty operations. Engineered with precision and durability in mind, this assembly serves as the foundation for the cab’s interior, supporting key systems while withstanding vibrations, impacts, and daily wear in construction, mining, and material handling environments.

Product Description of XCMG Wheel Loaders Floor Assembly

Core Structural Components
The assembly begins with the Front Bracket, a high-strength steel framework secured to the cab’s chassis using Bolt M12×25 and Washer 12 pairs, providing a stable base for forward-mounted controls. The Middle Plate and Triple Middle Plate form the central load-bearing structure, reinforced to distribute weight evenly across the loader’s frame. These plates are fastened with Bolt M8×20 and Washer 8, ensuring rigidity under dynamic loads. Rear support is provided by Rear Plate I, Rear Plate II, and Rear Plate III, which anchor the seat and rear-facing components, creating a balanced structural system.
Control Systems Integration
The floor assembly seamlessly integrates operator interfaces, including the Duplex Joystick System and Triple Joystick System, designed for precise control over lifting, tilting, and gear shifting. These systems are housed within the Maneuvering Cover Plate and Triple Maneuvering Cover Plate, secured with Bolt M10×30 and Washer 10 to protect internal linkages from dust and debris. The Hand Control Parking Brake is strategically positioned for easy access, ensuring safe machine immobilization during maintenance or steep incline operation.
Comfort and Safety Features
A Rubber Floor Plate lines the assembly, offering anti-slip traction, noise reduction, and vibration damping to enhance operator comfort during long shifts. This rubber layer is secured with corrosion-resistant fasteners, including Bolt Washer M10×30 and Bolt 10 Washer, to prevent displacement. The Seat Assembly mounts directly to the middle plate, with adjustable rails for personalized positioning, while an Extinguisher is integrated into the rear structure for quick access in emergency situations, adhering to international safety standards.
Fastening and Durability
Every connection in the floor assembly is engineered for reliability: Bolt M12×25 with dual Washer 12 ensures secure front bracket mounting, while redundant Washer 8 on M8 bolts minimizes fastener loosening from vibrations. The use of high-tensile steel in brackets and plates, combined with electrophoretic coatings, protects against rust and abrasion, extending the assembly’s service life in harsh, wet, or dusty environments.
Engineering Excellence for Operational Efficiency
XCMG’s floor assembly undergoes rigorous testing for load capacity, fatigue resistance, and ergonomic design. The triple joystick system layout optimizes operator reach, reducing strain during repetitive movements, while the modular design of rear plates allows for easy access to under-floor components—such as hydraulic lines and electrical wiring—simplifying maintenance and minimizing downtime.
Conclusion: Robust Foundation for Productive Operations
The XCMG Wheel Loaders Floor Assembly delivers a perfect blend of structural integrity, operator-centric design, and safety features, serving as the backbone of the cab’s functional efficiency. By integrating heavy-duty materials, precision fastenings, and intuitive control systems, it ensures operators can work comfortably and safely, even in the most demanding worksite conditions—making it a trusted choice for professionals who prioritize performance and reliability.

Product Parameters of XCMG Wheel Loaders Floor Assembly

Sr.No.	Part No.	Description	Q’ty	Remark
1	4005066	Bolt M12×25	8	GB5783-86
2	4401009	Washer 12	8	GB93-87
3	4404010	Washer 12	8	GB97.1-85
4	9365562	Front Bracket	1
5	9364693	Duplex Joystick System	1
6	9364697	Triple Joystick System	1	Matching triple
7	9365546	Middle Plate	1
8	9365548	Triple Middle Plate	1	With triplex operation
9	4005040	Bolt M8×20	15	GB5783-86
10	4404008	Washer 8 Washer	15	GB97.1-85
11	4401007	Washer 8 Washer	15	GB93-87
12	9365736	Maneuvering Cover Plate	1
13	9365737	Triple Maneuvering Cover Plate	1	With triplex manipulation
14	5006088	Seat Assembly	1
15	9365550	Rear Plate I	1
16	9365552	Rear Plate II	1	With warm air
17	9365554	Rear Plate III	1	With air conditioner
18	9365556	Rubber Floor Plate	1
19	4005054	Blot Washer M10×30	3	GB5783-86
20	4401008	Bolt 10 Washer	3	GB93-87
21	4404009	Blot Washer 10	3	GB97.1-85
22	9364999	Hand Control Parking Brake	1
23	9357226	Extinguisher	1	Optional
