XCMG Wheel Loaders Diesel Tank Assembly

XCMG Wheel Loaders Diesel Tank Assembly: Reliable Fuel Storage and Delivery Solution
The XCMG Wheel Loaders Diesel Tank Assembly is a meticulously engineered component designed to provide robust, efficient, and safe fuel storage for XCMG wheel loaders. Engineered with high-quality materials and precision manufacturing, this assembly ensures uninterrupted operation of heavy-duty machinery in the most demanding construction and industrial environments.

Product Description of XCMG Wheel Loaders Diesel Tank Assembly

Tank Body: The Core of Fuel Storage
The Tank Body serves as the central structure of the assembly, crafted from durable, high-grade steel to withstand impacts, corrosion, and the rigors of continuous use. Its robust design offers ample capacity to store a significant amount of diesel fuel, ensuring extended operation time for wheel loaders without frequent refueling. The tank body’s interior surface is treated to prevent rust and contamination, safeguarding the quality of the fuel and maintaining the longevity of the loader’s engine.
Level Gauge: Accurate Fuel Monitoring
Integrated into the tank assembly is the Level Gauge, a crucial component that allows operators to precisely monitor the diesel fuel level. This gauge provides real-time information, enabling operators to plan refueling schedules efficiently and avoid unexpected fuel shortages during critical operations. Its clear and easy-to-read design ensures that fuel levels can be quickly checked, enhancing operational efficiency and minimizing downtime.
Sealing and Protection Components
To maintain the integrity of the fuel system, the assembly features a series of sealing elements. O-Rings are strategically placed at various connection points to create airtight and leak-proof seals, preventing fuel leakage and evaporation. These O-rings, made from high-quality elastomeric materials, offer excellent resistance to diesel fuel and harsh environmental conditions, ensuring long-lasting performance.
Screw Plugs are used to seal off openings when not in use, further protecting the fuel system from contaminants. Complemented by Seal Washers, these plugs create a double-layered sealing mechanism, enhancing the overall reliability of the tank assembly. The Seal Washers, designed to conform to the mating surfaces, distribute pressure evenly, eliminating the risk of fuel seepage.
Fastening and Support
A combination of Bolts, Washers, and Seal Washers is employed to securely fasten various components of the assembly. The Bolts, constructed from high-tensile steel, provide the necessary clamping force to hold the tank body and other parts in place, ensuring stability during the loader’s operation. Washers are placed between the bolts and the components to distribute the load evenly, preventing damage to the surfaces and enhancing the durability of the fastening system. The use of multiple washers at critical connection points further reinforces the assembly, guaranteeing a secure and vibration-resistant installation.
Fuel Filtration and Delivery
The Oil Filter plays a vital role in maintaining the cleanliness of the diesel fuel. Positioned to filter out impurities, dirt, and debris, it prevents these contaminants from entering the engine, protecting it from premature wear and damage. By ensuring that only clean fuel reaches the engine, the oil filter contributes to improved engine performance, reduced maintenance costs, and extended engine life.
The Oil Injecting Hole is designed for convenient refueling. Its strategic placement allows for easy access, enabling quick and efficient fueling of the wheel loader. The hole is equipped with proper sealing mechanisms to prevent spills and ensure a safe refueling process.
In summary, the XCMG Wheel Loaders Diesel Tank Assembly is a comprehensive solution that combines durability, functionality, and safety. With its robust tank body, accurate level gauge, reliable sealing components, secure fastening system, and efficient fuel filtration, it provides a dependable fuel storage and delivery system for XCMG wheel loaders. Whether working on construction sites, mining operations, or other heavy-duty applications, this assembly ensures that wheel loaders have the fuel they need to perform at their best, day in and day out.

Product Parameters of XCMG Wheel Loaders Diesel Tank Assembly

Sr. No.	Part No.	Part	Ｑ’ty
1	330E.1.1.1	Tank Body	1
2	YWZ-127	Level Gauge	1
3	GB1235-76	O- Ring	1
4	ZL40.1.3-7	Screw Plug	1
5	GB5783-86	Bolt	4
6	XGXL2-10×0.63	Oil Filter	1
7	Z3.1A.1.1A	Oil Injecting Hole	1
8	GB5783-86	Bolt	4
9	GB93-87	Washer	4
10	Z3.1A.1-1	Seal Washer	1
11	Z3(LT).1-6A	Bolt	4
12	JB982-77	Washer	4
13	XGXL5-10×100	Oil Filter	1
14	JB982-77	Washer	1
15	GB97.1-85	Washer	4
16	GB93-87	Washer	4
17	GB5783-86	Bolt	4
