XCMG Handle Assembly (Left)

The XCMG Handle Assembly (Left) is a meticulously crafted mechanical component engineered to offer unparalleled control and reliability for heavy-duty equipment operating in the most challenging industrial environments. With a focus on durability, precision, and user – friendliness, this assembly integrates a series of high – quality components that cooperative work to enhance the overall performance of the machinery.

Product Description of XCMG Handle Assembly (Left)

Structural Foundation
The CASING forms the outer shell of the XCMG Handle Assembly (Left), providing a sturdy and protective enclosure for all internal components. It safeguards the delicate inner workings from external impacts, dust, and moisture. The Plate serves as a crucial structural support, reinforcing the casing and ensuring stability during operation. These two elements together create a robust foundation for the entire assembly.
Core Operational Components
At the heart of the assembly lies the SPOOL, a precision – machined component that acts as the central control element. It translates the operator’s movements into hydraulic or mechanical signals, enabling accurate machinery control. Paired with the PUSH ROD, it ensures smooth and consistent linear motion, reducing friction and wear over time. The DISC PLATE provides a stable platform for rotational movements, while BUSHINGs positioned around the spool offer essential support, minimizing lateral movement and enhancing the precision of the handle’s operation.
Sealing and Protection
Sealing is of utmost importance for maintaining the assembly’s performance. The Sealing Gasket WASHER and O – RINGs work in tandem to create tight seals, preventing the leakage of hydraulic fluids and the ingress of contaminants. The PLUG secures vulnerable access points, further enhancing the sealing integrity. The DUST COVER acts as a barrier against dust, debris, and moisture, protecting the handle from external elements that could potentially compromise its functionality. This comprehensive sealing and protection system significantly extends the assembly’s lifespan and reduces maintenance requirements.
Spring and Fastening Systems
The Spring and SPRING SEAT combination provides the necessary return force, ensuring that the handle returns to its neutral position smoothly and promptly after the operator releases it. The SPRING PIN locks the moving parts in place, preventing any accidental displacement during vibrations or heavy – duty operation. High – strength BOLTs and NUTs, along with WASHERs, are used to securely fasten the assembly to the machinery. The WASHERs distribute the clamping force evenly, preventing surface damage and ensuring a stable connection that can withstand the rigors of heavy – equipment use.

The XCMG Handle Assembly (Left) is designed with precision in mind. The SEAL and additional BUSHINGs not only enhance the handle’s ergonomic design by reducing the force required for operation but also contribute to its structural integrity. Each component, from the corrosion – resistant Spring to the precisely – cut SPOOL, is engineered to meet strict OEM standards. This ensures seamless compatibility with XCMG machinery and other heavy – equipment models, making it an ideal choice for a wide range of industrial applications. Whether in construction, mining, or other heavy – industry sectors, the XCMG Handle Assembly (Left) offers reliable, precise control, and long – term value.

Product Parameters of XCMG Handle Assembly (Left)

ITEM	PART NO.	PART NAME	Q’TY
101	860120174	CASING	1
111	860120175	Plate	1
121	860120176	Sealing Gasket WASHER	2
122	860120177	O-RING	1
125	860120178	BOLT	2
126	860120179	SPRING PIN	1
131	860120180	BUSHING	1
151	860120181	DISC PLATE	1
201	860120182	SPOOL	4
211	860120183	PLUG	4
212	860120184	PUSH ROD	4
213	860120185	SEAL	4
214	860120186	O-RING	4
216	860120187	SPRING SEAT	4
217	860120188	WASHER	4
221	860120189	Spring	4
241	860120190	Spring	4
312	860120193	NUT	1
501	860120198	DUST COVER	1
