The XP305KS tire roller is a heavy-duty tire roller manufactured to meet market demands. It uses pneumatic tires as its working mechanism to compact paving materials. It is primarily suitable for compaction work on asphalt pavements, base courses, sub-base courses, dams, and embankment projects, making it the ideal compaction equipment for the construction of high-grade highways, airports, ports, dams, and industrial construction sites.
XP305KS Pneumatic Tire Roller
The XCMG XP305KS pneumatic tire roller is purpose-built for final compaction of asphalt pavement layers where surface sealing and uniform density are critical quality requirements. Its multiple pneumatic tires exert a combined kneading and pressing action that eliminates air voids while preserving the aggregate structure within the asphalt mix.
Unlike conventional steel drum rollers that rely solely on vertical pressure, the XP305KS employs flexible tire contact patches to manipulate the material from multiple angles. This produces a tightly sealed surface with enhanced resistance to moisture infiltration and long-term weathering.
Operators benefit from a spacious cab environment with intuitive controls that reduce fatigue during extended shifts. The machine incorporates advanced vibration damping throughout the chassis and operator station, significantly lowering whole-body vibration exposure compared to older generation models.
The XP305KS features a strategically arranged set of pneumatic tires that provide overlapping coverage across the full compaction width. This staggered pattern ensures no gaps or uncompacted strips remain after each pass. The tire arrangement generates a consistent ground pressure profile from edge to edge.
Individual tire inflation can be adjusted according to project specifications, allowing operators to fine-tune the contact pressure for different asphalt mix designs. Higher inflation pressures concentrate force for deeper lifts, while lower pressures spread the load across a wider contact area.
At the core of the XP305KS lies a high-torque diesel engine delivering reliable power across all operating conditions. The powertrain is matched to a hydrostatic drive system that offers smooth acceleration and precise speed control without abrupt jerking that could mar the compacted surface.
Fuel consumption has been optimized through intelligent engine management and reduced parasitic losses in the hydraulic circuits. This translates to lower operating costs over the machine’s service life and reduced environmental impact from emissions on the job site.
XCMG has prioritized operator wellbeing in the XP305KS design. The ROPS-certified cabin provides excellent panoramic visibility of the tire array and surrounding work area. Ergonomic seat adjustments, climate control, and strategically positioned controls minimize physical strain during long working hours.
Safety features include an emergency stop system, comprehensive lighting packages for night operations, and slip-resistant access platforms. The machine’s low center of gravity and wide stance contribute to exceptional stability on graded surfaces and moderate slopes.
Every structural component of the XP305KS is built to withstand the punishing conditions of heavy civil construction. The frame utilizes high-strength steel alloys with reinforced stress points identified through finite element analysis during the design phase.
Corrosion-resistant coatings protect exposed surfaces from moisture, road salts, and chemical agents commonly encountered on construction sites. Critical pivot points feature sealed bearings that require minimal maintenance while providing years of trouble-free operation in dusty environments.
The XP305KS pneumatic tire roller excels in projects where surface quality directly impacts long-term pavement performance. Highway construction crews rely on this machine for the final compaction pass on asphalt wearing courses, where it creates a dense, impermeable surface layer that resists cracking and rutting.
Airport runway and taxiway projects demand the highest standards of smoothness and durability, making the XP305KS a preferred choice among aviation infrastructure contractors. Its ability to compact without inducing surface fractures is particularly valuable for airfield pavements subject to heavy aircraft loading.
Urban road rehabilitation and large commercial site development also benefit from the roller’s maneuverability and consistent output. Bridge deck overlays, industrial yard paving, and port container terminal surfaces represent additional applications where the XP305KS delivers measurable quality improvements.
| Parameter | Specification |
|---|---|
| Operating Weight | 30,000 kg |
| Maximum Working Speed | 8 km/h |
| Maximum Travel Speed | 16 km/h |
| Number of Tires (Front + Rear) | 5 + 6 (11 total) |
| Compaction Width | 2,750 mm |
| Ground Pressure Range | 200 – 550 kPa |
| Rated Engine Power | 132 kW @ 2,200 rpm |
| Engine Model | Cummins QSB6.7 (Tier 3 / Stage IIIA) |
| Gradeability | 20% |
| Minimum Turning Radius | 7,000 mm |
| Fuel Tank Capacity | 200 L |
| Hydraulic Oil Capacity | 110 L |
| Overall Length × Width × Height | 5,200 × 2,800 × 3,450 mm |
| Wheelbase | 3,800 mm |
| Tire Size | 11.00-20 16PR |
| Drive System | Hydrostatic, full-time all-wheel drive |
Selecting the right compaction equipment directly influences project timelines, pavement longevity, and overall profitability. The XP305KS offers a compelling combination of proven engineering, accessible maintenance, and competitive total cost of ownership that distinguishes it from alternatives in its class.
XCMG’s global service network ensures that parts and technical support are readily available wherever projects are located. The XP305KS shares common components with other XCMG roller models, simplifying fleet maintenance and reducing the inventory of spare parts that contractors need to stock.
The machine’s resale value remains strong due to XCMG’s reputation for manufacturing durable equipment that retains its capabilities after years of intensive use. Fleet managers appreciate the straightforward diagnostic systems that minimize troubleshooting time and keep the roller productive on tight construction schedules.
From initial site preparation through project completion, the XP305KS delivers consistent compaction results that meet stringent quality specifications. Its combination of power, precision, and operator-friendly design makes it a valuable asset for any contractor serious about pavement quality and operational efficiency.
