The XCMG XP265KSIV pneumatic tire roller is a high-performance compaction machine built for demanding asphalt jobs. Its robust multi-tire design kneads and seals the surface, ensuring uniform density across the full working width.
Engineered for fuel efficiency and operator comfort, the XP265KSIV tackles thick lifts and thin overlays with equal precision. It delivers a smooth, watertight mat that resists cracking and prolongs pavement life.
From highways to airport runways, this machine provides the power and reliability that contractors trust. Experience superior compaction results and lower long-term maintenance costs.
XP265KSIV Pneumatic Tire Roller
The XP265KSIV pneumatic tire roller has been developed to meet the strictest specifications of modern road construction. Its balanced weight distribution and flexible rubber tires create a powerful kneading action that closes air voids in the asphalt layer.
Compared to conventional steel drum rollers, the XP265KSIV leaves behind a denser, more uniform surface. The independent movement of each tire allows the machine to follow ground contours accurately, preventing bridging over low spots and ensuring consistent compaction from edge to edge.
XCMG has integrated a proven hydrostatic drive system that gives the operator precise control over speed and direction. This not only improves mat quality but also reduces the risk of asphalt tearing or shoving during the rolling sequence.
The XP265KSIV employs a staggered arrangement of front and rear tires that covers every inch of the compaction path. The flexible rubber casings conform to surface texture variations while applying vertical and lateral forces that reorient aggregate for maximum density.
A turbocharged, electronically governed diesel engine provides ample reserve power for steep gradients and heavy towing. The efficient combustion system reduces fuel consumption while meeting international emissions standards, making the roller both powerful and environmentally responsible.
The fully digital instrument panel displays essential parameters such as tire pressure, speed, engine temperature, and service alerts in real time. Operators can adjust compaction speed seamlessly with a single lever, reducing fatigue and improving consistency across long shifts.
High-strength steel frame rails with reinforced articulation joints endure the continuous flexing and vibration typical of heavy compaction work. Sealed pivot bearings keep out dust and water, greatly extending service intervals and reducing unexpected downtime.
A pressurized water distribution system keeps tire surfaces clean and conditioned to prevent pick-up of hot asphalt. The large water tank supports uninterrupted operation for extended periods, while adjustable nozzles let the operator fine-tune coverage based on mix temperature.
Noise-dampening panels and a highly efficient cooling system reduce the machine’s environmental footprint without sacrificing output. The engine’s low-speed torque characteristic also contributes to quieter operation in noise-sensitive urban job sites.
| Parameter | Specification |
|---|---|
| Operating Weight | 27,000 kg |
| Maximum Operating Weight | 31,500 kg |
| Number of Tires (Front + Rear) | 5 + 6 |
| Compaction Width | 2,800 mm |
| Travel Speed (Forward / Reverse) | 0 – 8 km/h / 0 – 8 km/h |
| Engine Model | Cummins QSB6.7 Turbocharged Diesel |
| Rated Power | 186 kW @ 2,200 rpm |
| Fuel Tank Capacity | 320 L |
| Water Tank Capacity | 550 L |
| Gradeability | 22% |
| Tire Size | 11.00-20 |
| Ground Pressure Range | 200 – 580 kPa |
| Overall Dimensions (L×W×H) | 5,300 × 2,800 × 3,450 mm |
| Minimum Turning Radius | 7,600 mm |
| Drive System | Hydrostatic Closed-Loop Circuit |
| Braking System | Hydraulic Service + Mechanical Parking Brake |
The XP265KSIV is the go-to machine for final compaction of asphalt pavements on highways, urban boulevards, and rural roads. Its ability to seal the surface against water ingress makes it indispensable for extending the service life of heavily trafficked routes.
On airport projects, the roller’s consistent ground pressure and precise speed control produce the ultra-smooth finish required for runways and taxiways. The sealed surface prevents water ponding, reducing the risk of hydroplaning and enhancing overall airfield safety.
The machine also excels on bridge deck overlays, industrial yards, and large parking lots where durability and visual quality are paramount. The adjustable tire pressure system enables quick adaptation to different mix designs and layer thicknesses without time-consuming mechanical changes.
Every aspect of the XP265KSIV has been refined to maximize productivity on the job site. The hydrostatic transmission provides jerk-free starts and stops, protecting the fresh mat while delivering constant travel speed irrespective of the load applied.
The ergonomic cab features a panoramic glass area that eliminates blind spots, giving the operator full awareness of the working zone. A vibration-isolated platform and adjustable seat reduce fatigue during long rolling sequences, keeping performance sharp throughout the day.
Maintenance has been simplified through centralized service points and an automatic lubrication system that feeds grease to critical pivot pins. Easy-open engine covers and grouped filters allow daily checks to be completed in minutes, keeping the roller on the job and off the service bay.
Contractors who run the XP265KSIV benefit from a machine that consistently passes density tests on the first attempt. The superior kneading action eliminates the need for excessive roller passes, saving fuel and cutting project timelines.
The durable construction and globally proven components mean high resale value and confidence in the machine’s longevity. XCMG’s worldwide parts and service network ensures that support is never far away, no matter where the project is located.
Choosing the XP265KSIV means investing in a partner that understands the realities of road building. From the intelligent control system to the robust water spray circuit, every feature is designed to help operators achieve the perfect finish with minimal hassle.
The XCMG XP265KSIV pneumatic tire roller sets a new standard for asphalt compaction efficiency. Its powerful engine, intelligent controls, and rugged structure combine to produce pavements that stand the test of time.
Whether you are resurfacing a city street or building a major highway, the XP265KSIV delivers the density, smoothness, and reliability required to meet today’s demanding specifications. Explore how this machine can elevate your next project.
