播放有关的视频 XE150WD Wheel Excavator

XE150WD Wheel Excavator

Product Feature

With cruise control function, it is suitable for long-distance driving on road. Using German ZF gearbox, smooth shifting, high control comfort, suitable for multi-curved road conditions. Equipped with dozer blade hydraulic holding valve, which improves the safety of operation compared with similar products.

Product Parameters

Item

Unit

XE150WD

Engine model

/

QSB4.5

Output power of engine

Kw/r/min

106/2000

Operating Weight

KG

14000

Max.torque/engine

N.m

586

Displacement

L

4.5

Fuel tank capacity

L

250

Rated flow of main pump

L/min

2×160

Pressure of main safety valve

Mpa

31.4/34.3

Hydraulic tank capacity

L

135

Slewing speed

r/min

12

Digging capacity of tcuket

KN

95

Digging capacity of tcuket rod

KN

72

Min.turning radius

mm

6500

Rated speed

KM/h

11/33

Gradient capability

%

70

A Total length

mm

7778

B Total width

mm

2495

C Total heigth

mm

3305

Counterweight ground clearance

mm

1230

Min.ground clearance

mm

355

Min.tail swing radius

mm

2300

Wheelbase

mm

2800

Track gauge

mm

1920

Total width of chassis

mm

2495

Distance between front axle and turning center

mm

1700

Hood height

mm

2430

The maximum digging depth of dozer

mm

105

Max. digging radius

mm

7780

Min. swing radius

mm

7570

Max. digging height

mm

8190

Max. dumping height

mm

5855

Max. digging depth

mm

4630

Maximum depth cut for 2240mm(8 ft) level bottom

mm

4325

Max. vertical wall digging depth

mm

4150
