XE105WG is a state-of-the-art wheeled backhoe loader designed to maximize productivity on urban, agricultural, and infrastructure projects. Its powerful 86 kW turbocharged engine and load-sensing hydraulic system ensure exceptional performance while reducing fuel consumption by up to 18%. The maximum travel speed reaches 38 km/h, enabling quick site changes and reducing logistics costs.
The XE105WG features a compact rear turning radius and a robust frame with a dozer blade and hydraulic stabilizers, offering unmatched stability on uneven terrain. Its spacious cab with air suspension and a 7-inch touchscreen enhances operator comfort, while the telematics system allows for real-time monitoring of the equipment. Ideal for trenching, loading, light demolition, and road maintenance.
| Operating Weight (kg) | 9800 kg |
|---|---|
| Standard Bucket Capacity (m³) | 0.4 m³ (Selectable: 0.35–0.5) |
| Engine Model | XCMG XC4DK80 (turbocharging) |
| Rated Power / RPM | 86 kW / 2200 rpm |
| Maximum Torque | 460 N·m |
| Travel Speed (High/Low) | 38 km/h / 10 km/h |
| Gradeability | ≥ 58% (30°) |
| Swing Speed (rpm) | 11.5 rpm |
| Bucket Digging Force (kN) | 68 kN |
| Boom Digging Force (kN) | 52 kN |
| Maximum Digging Radius (mm) | 7620 mm |
| Maximum Digging Depth (mm) | 4850 mm |
| Maximum Dumping Height (mm) | 5780 mm |
| Tail Swing Radius (mm) | 2230 mm |
| Wheelbase (mm) | 2650 mm |
| Fuel Tank Capacity (L) | 170 L |
| Hydraulic Oil Tank Capacity (L) | 120 L |
At the heart of the XE105WG is an XCMG common-rail direct-injection engine that meets EU Stage V emissions standards. The electronic control system optimizes the power-to-fuel-consumption ratio, achieving fuel savings of up to 15% under real-world job site conditions. The variable-flow hydraulic control system reduces losses and improves precision during simultaneous operations.
Thanks to the automatic idle mode and intelligent coolant temperature control, the machine extends maintenance intervals. In addition, the DOC+DPF aftertreatment system ensures clean, smoke-free emissions, making it ideal for projects in urban areas or areas with environmental restrictions. Its reliability has been tested for over 2,000 hours under extreme conditions.
The cab of the XE105WG features a soundproofed environment (72 dB(A)), an ergonomic seat with optional heating, and automatic climate control. The 7-inch touchscreen integrates machine diagnostics, maintenance alerts, and a backup camera. Proportional control joysticks enable smooth and precise operation, reducing operator fatigue during long shifts.
XCMG’s “iLink” telematics system sends real-time data to the cloud platform: hourly fuel consumption, GPS location, fault alerts, and engine performance. Fleet managers can schedule predictive maintenance and set geofences, maximizing machine uptime. All of this can be done from a smartphone or PC.
The superstructure of the XE105WG uses high-strength steel at critical points, with an electrophoretic anti-corrosion coating. The wheeled undercarriage features disc brakes on all wheels and rollover protection (ROPS/FOPS) in the cab. The rear stabilizers and dozer blade, made of reinforced sheet metal, ensure stability during lifting operations and when digging deep trenches.
The hydraulic hoses are Parker brand, abrasion-resistant, and heat-resistant. The automatic lubrication system (optional) extends the service life of the pins and bushings. The excavator has passed rigorous fatigue tests, offering an estimated service life of over 12,000 hours under normal operating conditions.
Thanks to its compact design and excellent maneuverability, the XE105WG is ideal for street repairs, landscaping, agricultural drainage, and material handling. The quick-change attachment system allows for the use of more than 20 accessories: hydraulic hammer, grapple, shear, dozer blade, etc. Its tight rear turning radius (2230 mm) makes it easy to work in confined spaces.
In infrastructure projects, the travel speed of 38 km/h drastically reduces downtime between jobsites. Contractors report a 22% increase in annual profitability compared to conventional tracked machines. The XE105WG is also ideal for rental, as it combines durability with low maintenance costs.
The design of the XE105WG facilitates daily access to service points: oil, fuel, and air filters can be inspected from the ground through wide-opening side doors. The engine oil change interval is 500 hours, which reduces operating costs. The centralized diagnostic panel allows for quick reading of error codes and resetting of parameters.
XCMG has an extensive global dealer network, offering genuine parts and technical support within 24 hours. Each unit comes with an interactive digital manual that includes maintenance videos. The standard warranty covers 2 years or 3,000 hours, with extension options available for fleets.
The XE105WG complies with European Stage V and EPA Tier 4 Final regulations. Particulate emissions are reduced by 80% compared to previous generations. The external noise level is only 98 dB(A), allowing for nighttime operation in residential areas. The use of biodegradable hydraulic oil is optional for sensitive applications such as nature parks or projects near water sources.
