The XD135T0S oscillating roller is equipped with a high-frequency oscillating drum, features an ultra-high tonnage, and delivers powerful compaction performance. With precisely optimized oscillation parameters, its compaction efficiency exceeds industry standards by 15%; oscillating compaction ensures minimal deflection, prevents over-compaction, and is energy-efficient and environmentally friendly. It can compact various materials and layers of different thicknesses, and is suitable for compacting subgrade and subbase materials. It is ideal for pavement compaction in large-scale projects such as roads and airports, and is particularly suitable for vibration-sensitive areas such as bridges.
XCMG XD135TOS Tandem Vibratory Roller
The XCMG XD135TOS tandem vibratory roller is purpose-built for medium to large-scale asphalt compaction projects. With an operating weight of 13,500 kilograms, this machine provides the optimal balance between compaction force and maneuverability. The dual smooth drum configuration ensures even pressure distribution across the entire working width, resulting in consistent mat density and superior surface finish. Engineers at XCMG have incorporated decades of compaction research into the XD135TOS design, creating a roller that meets the rigorous demands of modern road construction standards worldwide.
Equipped with a high-performance Cummins diesel engine, the XD135TOS delivers reliable power output while maintaining excellent fuel efficiency. The advanced hydraulic system provides smooth and responsive control over all machine functions, from vibration activation to travel speed adjustment. Each component has been selected and tested for durability under continuous heavy-duty operation, ensuring that the XD135TOS remains productive throughout long work shifts and extended project timelines.
The one-piece hood slides upward, providing a clear view of the entire engine compartment;
Wear-prone components are located in easily accessible positions or can be replaced without the need to remove many other parts.
37 Hz high-frequency vibration significantly reduces operating time; Infinite variable speed control from 0 to 12 km/h meets the demands of various work scenarios.
The front-and-rear-supported rotating skid steering system features a seat that is adjustable for fore/aft and height, with adjustable weight support. The seat can also slide left/right and rotate, allowing the operator to easily observe conditions around the wheels and on the wheel surfaces;
The cab sides feature a 2° slant to enhance visibility, while the spacious cab increases operating space and improves operational comfort.
On highway construction projects, the XD135TOS consistently achieves target density specifications in fewer passes compared to previous generation models. The optimized drum dimensions and weight distribution allow the roller to cover more ground per hour, directly contributing to shorter project completion times. Contractors appreciate the machine’s ability to maintain steady compaction quality even when working on longitudinal joints and transverse construction joints, areas traditionally challenging for uniform density achievement.
The low center of gravity design enhances machine stability when operating on sloped surfaces or when making tight turns at the end of each pass. This stability translates to confident operation and reduced risk of machine tipping, even on superelevated curves common in highway interchange construction. The XD135TOS has demonstrated reliable performance across diverse climate conditions, from hot summer paving in desert regions to cool-weather compaction in mountainous terrain.
Fuel economy is another significant advantage of the XD135TOS. The engine management system optimizes fuel delivery based on actual load conditions, reducing consumption during idling and light-load operation. Over the course of a full construction season, the cumulative fuel savings can represent a substantial reduction in operating costs, improving the return on investment for equipment owners and rental fleet managers alike.
The XD135TOS tandem vibratory roller is ideally suited for a wide range of compaction applications. On highway and expressway projects, it handles both binder course and wearing course compaction with equal proficiency. The machine excels on airport runway paving where strict smoothness and density specifications demand the highest levels of compaction precision. Municipal road departments rely on the XD135TOS for city street resurfacing projects, where its maneuverability allows efficient operation in confined urban environments.
Industrial paving applications such as container yards, logistics centers, and port facilities benefit from the XD135TOS heavy-duty construction and consistent compaction output. The machine is also effective on large parking lot construction, sports surface base preparation, and other flatwork projects requiring uniform asphalt density. Its versatility across these varied applications makes the XD135TOS a valuable asset for construction companies seeking to maximize equipment utilization across multiple project types.
| Parameter | Specification |
|---|---|
| Operating Weight | 13,500 kg |
| Maximum Operating Weight | 14,200 kg |
| Drum Width (Front & Rear) | 2,130 mm |
| Drum Diameter | 1,300 mm |
| Static Linear Load | 317 N/cm |
| Vibration Frequency (High/Low) | 55 Hz / 45 Hz |
| Nominal Amplitude (High/Low) | 0.75 mm / 0.35 mm |
| Centrifugal Force (High/Low) | 170 kN / 110 kN |
| Engine Model | Cummins QSB4.5 |
| Rated Engine Power | 119 kW @ 2,200 rpm |
| Travel Speed (Forward/Reverse) | 0 – 12 km/h |
| Maximum Gradeability | 30% |
| Fuel Tank Capacity | 280 L |
| Water Tank Capacity | 700 L |
| Overall Length | 5,020 mm |
| Overall Width | 2,380 mm |
| Overall Height | 3,100 mm |
| Steering Type | Articulated Hydraulic |
| Vibration System | Dual Frequency / Dual Amplitude |
| Drum Surface Type | Smooth (Machined) |
XCMG has designed the XD135TOS with serviceability as a core consideration. All routine maintenance points are accessible from ground level through wide-opening service doors. The engine compartment provides ample clearance for filter changes and fluid level checks, reducing technician time spent on preventive maintenance tasks. Grease points for the articulation joint and drum bearings are centralized for convenient access, encouraging consistent lubrication practices that extend component service life.
The hydraulic system uses high-quality filtration to protect sensitive components from contamination, a leading cause of hydraulic failures in compaction equipment. Extended oil change intervals validated by XCMG engineering reduce the frequency of scheduled maintenance stops, keeping the XD135TOS productive on the job site. A comprehensive diagnostic port allows technicians to quickly identify and troubleshoot any system issues, minimizing downtime when service is required.
Investing in the XD135TOS brings measurable cost advantages to asphalt paving contractors. The machine’s ability to achieve specified density in fewer passes directly reduces fuel consumption per square meter of compacted asphalt. When calculated across large highway projects spanning hundreds of thousands of square meters, this efficiency gain represents a significant reduction in total project compaction costs. The dual-frequency vibration system eliminates the need for a separate breakdown roller in many paving train configurations.
Parts commonality across the XCMG tandem roller product line simplifies inventory management for fleet owners operating multiple XCMG machines. Consumable items such as filters, belts, and drum scrapers are readily available through XCMG’s global parts distribution network. This parts availability combined with the machine’s inherent reliability results in industry-leading uptime percentages, ensuring that the XD135TOS contributes maximum productive hours to every construction season.
Every XCMG XD135TOS tandem vibratory roller undergoes rigorous factory testing before delivery to ensure it meets all performance specifications. The manufacturing process follows ISO 9001 quality management standards, with critical components subjected to non-destructive testing to verify structural integrity. Vibration system calibration is performed and verified on each machine to guarantee that specified frequency and amplitude outputs are achieved under load conditions.
The XD135TOS complies with international safety standards including ROPS (Roll-Over Protective Structure) and FOPS (Falling Object Protective Structure) certification for the operator cabin. Noise emission levels are controlled within regulatory limits through engine enclosure design and exhaust system optimization. These compliance credentials make the XD135TOS suitable for deployment on projects funded by international development banks and agencies that require equipment meeting recognized safety and environmental standards.
