XD133S vibratory roller is designed intended for compacting asphalt pavement. It also can be used to compact layer of different materials and different thickness. With a wide application range it is very suitable for surface compaction work for public roads, parking lots, airports and other large engineering projects, as well as the compaction work on roadbed and sub-base material.
Description | Unit | Parameter value | ||
Working weight | kg | 13200 | ||
Front wheel distribution weight | kg | 6600 | ||
Rear wheel distribution weight | kg | 6600 | ||
Static linear load | N/cm | 305/305 | ||
Nominal amplitude | mm | 0.30/0.80 | ||
Vibration frequency | Hz | 67/50 | ||
Exciting force (high frequency/low frequency) | kN | 110/170 | ||
Vibration wheel size | mm | 1300×2130 | ||
Speed range | km/h | 0-6,0-8,0-12 | ||
Theoretical gradeability | % | 35 | ||
Minimum turning radius | mm | 4470/6600 | ||
Swing angle | ±8° | |||
Steering angle | ±35° | |||
Engine | Model | DEUTZ BF4M1013-15T3R/2 | ||
Type | Inline four-cylinder pressurized water-cooled | |||
Rated speed | r/min | 2100 | ||
Rated power | kW | 111 | ||
