XCMG Track Pad

The mud-drainage holes in the track plates are custom-designed based on different host machine configurations and operating conditions, reducing damage to the tracks caused by external debris and extending the service life of the track plates;
Utilizing integral spray quenching heat treatment, the product’s flatness control surpasses that of domestic competitors. It features uniform cross-sectional hardness, excellent mechanical properties, and superior wear resistance;
Heavy-duty mining track plates employ a “double-tooth” design and beveled ends, which not only effectively enhance track traction but also prevent bolt loosening and breakage caused by lateral compression during machine turns.

Product Parameters Of XCMG Track Pad

Code Name	Type	A	B	C	D	E	F	L	O	Application
Code Name	Type	A	B	C	D	E	F	L	O	Application
XDL135	A	104	80	46	6	20	154	400	12.5	6t Excavator
XDL154	A	112.4	82.4	57	6/8	26/28	165/164	450	14.5	8t~9t Excavator
XDL154A	A	89	73	57	6/8	26/28	165/164	450	14.5	7.5t Excavator
XDL171	A	108	108	60.3	8	28/33	190/ 198.9	600	16.5	15t Excavator
XDL175	A	102.4	86.4	57	8/9.5	33/29.5	198.9/190	500	16.5	13t~15t Excavator
XDL190	A	160.4	124.4	62	8.5/10/12	34.5/36/38	219	600	20.5	20t~27t Excavator
XDL203A	A	178.4	138.4	72.2	13	41	236	600	20.5	33t Excavator
XDL203B	A	179	129	72	11	39	236	600	20.5	26.5t Excavator
XDL216	A	184	146	76.2	13/16	49/52	247	600	24.5	36t~40tExcavator
XDL216B	A	178.4	140.4	76.2	11/13	41/49	250/247	600	22.5	30t~33t Excavator
XDL228	A	184	144	76.2	16	52	247	600	24.5	45t~50t Excavator
XDL90G	B	—	—	—	5.5	22	90	230	—	1.5t Excavator
XDL101G	B	55.5	55.5	23.5	6.5	22.5	110	300	12.5	3.5t Excavator
XDL190	B	160.4	124.4	62	13	48	219	600	20.5	20t~27t Excavator
XDL203B	B	179	129	72	14.5	56.5	235	600	20.5	26.5t Excavator
XDL216	B	184	146	76.2	15.5	64.5	251	600	24.5	36t~40tExcavator
XDL216B	B	178.4	140.4	76.2	15.5	64.5	251	600	22.5	30t~33t Excavator
XDL228	B	184	144	76.2	15.5	64.5	251	600	24.5	45t~50t Excavator
XDL228D	B	219.8	169	76.2	19.5	68.5	252	600	24.5/26	65t Excavator
XDL190	C	160.4	124.4	62	13	70	225	960	20.5	13t林业机
Note: The above are standard products; we can customize the design and manufacturing to meet your specific needs.
