The XCMG GR2605TIV 5 Series Motor Grader is a heavy-duty earthmoving solution engineered for contractors who require exceptional power, relentless durability, and pinpoint grading accuracy on the toughest job sites. Designed to master large-scale highway construction, mining haul roads, and major infrastructure projects, this motor grader combines a high-torque engine with an advanced blade control system that delivers consistent results pass after pass.
With a robust frame and a spacious operator station, the GR2605TIV turns long shifts into productive, comfortable work sessions, ensuring operators can maintain focus and precision throughout the day.
XCMG GR2605TIV 5 Series Motor Grader
The XCMG GR2605TIV 5 Series Motor Grader represents a significant step forward in mid-to-large motor grader design, offering 260 horsepower of reliable muscle for serious earthmoving. This machine is purpose-built for contractors who cannot compromise on performance, uptime, or grading accuracy. Its powerful engine and heavy-duty drivetrain work seamlessly to push through tough materials while maintaining the smooth control needed for finish work.
Every structural component has been reinforced to handle the intense stress of continuous operation in mining, road building, and land reclamation. The GR2605TIV delivers exceptional blade downforce and side-shift capability, allowing operators to tackle deep cuts, wide spreading, and steep slope grading without struggling. This grader truly shines when the work demands both brute force and finesse.
Operators benefit from a state-of-the-art cab that prioritizes visibility, ergonomics, and climate comfort. The large glass area and strategically positioned control levers make grading feel intuitive, reducing learning curves for new operators and fatigue for veterans. Maintenance teams also appreciate the ground-level access to daily check points, which streamlines service routines and maximizes machine availability.
1. Equipped with a load-sensing hydraulic system, it requires minimal operating force, provides excellent control feel, and offers responsive system performance.
2. Features engine variable power control technology for enhanced fuel efficiency.
3. Incorporates intelligent fan control technology, allowing fan speed to adjust based on real-time system temperature monitoring, resulting in low energy consumption and minimal noise.
4. Equipped with electronically controlled dual-lever control technology, integrating cylinder control, steering, and travel functions into a single system to reduce operator fatigue.
5. Features a wet-brake drive axle for extended service life and enhanced reliability.
6. Features a ROPS & FOPS-certified cab for improved safety; the optimized interior layout and controls meet ergonomic requirements, providing greater comfort.
7. The air conditioning ducts are integrated into the cab interior design, resulting in a more aesthetically pleasing appearance and improved cooling performance.
8. Advanced vibration damping and noise reduction technology is employed, resulting in low overall machine noise levels.
9. The use of an integrated angle positioner, high-strength slewing bearing, and overload-protected worm gearbox ensures higher reliability of the working equipment.
10. The optimized machine layout allows for ground refueling and strategically placed maintenance access points, making servicing more convenient.
11. Equipped with a rearview camera system to expand rear visibility and enhance safety.
| Parameter | Specification |
|---|---|
| Engine Model | Weichai WD12G260E3 / Cummins QSB6.7 |
| Rated Power | 194 kW / 260 HP @ 2,200 rpm |
| Operating Weight | 20,300 kg (44,753 lbs) |
| Blade Length | 4,320 mm (14 ft) |
| Blade Height | 680 mm (26.8 inches) |
| Max Grading Width | 2,800 mm (9.2 ft) |
| Max Lifting Height Above Ground | 500 mm (19.7 inches) |
| Max Cutting Depth | 550 mm (21.6 inches) |
| Forward Travel Speeds | 5 / 8 / 12 / 17 / 24 / 33 / 42 / 52 km/h (8 speeds) |
| Reverse Travel Speeds | 6 / 14 / 25 / 36 km/h (4 speeds) |
| Gradeability | 22° (40.4%) |
| Minimum Turning Radius | 8.0 m (26.2 ft) |
| Transmission Type | Powershift with Torque Converter |
| Tire Size | 20.5-25 PR16 |
| Overall Length | 9,350 mm (30.68 ft) |
| Overall Width | 2,780 mm (9.12 ft) |
| Overall Height | 3,580 mm (11.75 ft) |
| Fuel Tank Capacity | 350 Liters (92.5 gallons) |
| Hydraulic Oil Tank Capacity | 145 Liters (38.3 gallons) |
| Blade Rotation Range | 360° continuous rotation |
The GR2605TIV 5 Series Motor Grader is the go-to machine for large-scale highway construction and resurfacing projects. Its wide moldboard and powerful engine enable efficient spreading and trimming of thick aggregate base layers. The precise hydraulic controls allow operators to cut final grades with minimal passes, accelerating project timelines and achieving the tight tolerances demanded by modern road engineering specifications.
In the mining sector, this grader excels at maintaining heavy haul roads subject to constant traffic from rigid dump trucks weighing hundreds of tons. The GR2605TIV’s robust structure withstands the punishing corrugations and potholes that develop on these roads, while its powerful circle drive aggressively cuts through compacted stone. Well-maintained haul roads contribute directly to lower fleet operating costs and improved mine safety records.
Major land development and airport runway construction also benefit from the GR2605TIV’s capabilities. The machine can be configured with optional front dozer blades or rear rippers to break up hard ground before grading, allowing it to serve as a multi-purpose platform. This versatility reduces the need for additional support equipment on site, giving contractors maximum return on their investment.
Large-scale agricultural operations and irrigation projects rely on the GR2605TIV for precise land leveling over extensive areas. The grader’s long wheelbase naturally averages high spots, while the sensitive blade controls permit slope creation for optimal water flow. This capability proves invaluable for rice paddies, cotton fields, and other crops requiring carefully managed water distribution across vast acreages.
Fuel economy is outstanding for a motor grader in this power class. The intelligent engine management system adjusts fuel delivery based on real-time load demands, preventing waste during idle or light grading. Combined with the efficient powershift transmission, the GR2605TIV uses significantly less fuel per cubic meter of material moved compared to older models, directly lowering the total cost of operation for fleet owners who run their machines over multiple shifts.
Service accessibility is a hallmark of XCMG design philosophy. The engine compartment opens wide, and all filters, fluids, and grease points are arranged for rapid inspection and service. This design consideration reduces the time required for daily maintenance walks and encourages technicians to follow preventive maintenance schedules diligently. The result is less unplanned downtime and a longer operational life for the machine.
Component durability is achieved through the use of globally sourced, high-quality parts and extensive factory testing. The blade linkage, articulation pins, and hydraulic cylinders are all oversized for their load ratings, providing a substantial margin of safety. Customers consistently report that GR series graders remain tight and responsive well past the 10,000-hour mark with proper care, proving the value of XCMG’s heavy engineering approach.
The GR2605TIV is engineered with a modular powertrain layout, meaning the engine, transmission, and axles can be removed individually for overhaul without disturbing other systems. This modularity is a major advantage during major repairs, as it allows work to be performed in parallel and shortens the overall repair timeline. It also gives owners the flexibility to exchange components with rebuilt units if desired, further reducing machine downtime.
Corrosion and wear protection are treated as priorities. The steel surfaces undergo shot blasting and priming before receiving a durable multi-layer paint finish. Inside the frame enclosed spaces are treated with anti-corrosion wax compounds. The blade’s cutting edge and end bits are made from heat-treated, replaceable wear steel, so operators can renew the grading edge quickly and inexpensively when it eventually wears down after extensive use in abrasive materials.
XCMG provides comprehensive documentation including illustrated parts catalogs, maintenance manuals, and troubleshooting guides. This information empowers local service teams to diagnose and resolve issues rapidly. Combined with XCMG’s global network of dealers and parts depots, the GR2605TIV is supported by a robust aftermarket infrastructure designed to keep machines productive and profitable wherever they are deployed around the world.
Selecting the XCMG GR2605TIV 5 Series Motor Grader means partnering with a manufacturer that understands the realities of heavy construction. This model brings together aggressive power, refined control, and rugged construction in a package that delivers genuine value over its entire service life. It is a machine built to tackle the projects that test the limits of both equipment and operators, and it does so without demanding an exorbitant purchase price.
The GR2605TIV is supported by XCMG’s worldwide commitment to customer satisfaction, with readily available parts, trained technicians, and responsive service support. When you choose this grader, you gain not only a powerful piece of equipment but also the confidence that comes from knowing your investment is protected by a company that stands firmly behind its products, ensuring minimal downtime and maximum productivity for years to come.
