Advanced land-leveling solutions featuring cutting-edge technology and proven performance in demanding conditions.
La The XCMG GR180II Series 3 motor grader is the ideal solution for grading projects that require pinpoint precision and operational efficiency. Designed with advanced technology and manufactured to the most rigorous quality standards, this machine delivers exceptional performance in demanding working conditions. Its high-powered engine and precision hydraulic system ensure superior results in every application.
XCMG GR180II 3 Series Motor Grader
The XCMG Series 3 model GR180II incorporates innovations that significantly improve productivity on road construction sites, in foundation work, and on large-scale earthmoving projects. Its robust design ensures a long service life with reduced operating costs.
Equipped with a Shangchai Stage II turbocharged engine and featuring an optimally selected torque converter orifice diameter, this design ensures optimal matching between the torque converter and the engine, reducing the vehicle’s startup and acceleration time while increasing torque output at low speeds for powerful performance.
By increasing the hydraulic system pressure, the blade rotation force is significantly enhanced. The ring gear undergoes high-frequency quenching treatment, improving wear resistance and service life, and enabling rotation operations under load.
The blade arc has been optimized to enable fast and efficient soil turning and discharge, achieving optimal load distribution and minimizing material accumulation within the turntable area.
Structural components undergo global CAE optimization, ensuring reliability, durability, and extended service life; the patented slewing bearing drive axle offers a long service life and higher reliability; the overload-protected worm gearbox and slewing bearing work unit provide enhanced adaptability; and the cast front axle joints ensure a longer service life.
High precision: Advanced hydraulic system for precise leveling with minimal tolerances and professional finishes on every pass.
Energy efficiency: An optimized engine that reduces fuel consumption and the machine’s total operating costs.
Proven durability: Components made from high-strength materials to withstand harsh working conditions.
| Technical Parameter | Specification | Unit |
|---|---|---|
| Engine Model | SC8D190G2B1 | — |
| Nominal Power | 140 / 190 | kW / HP |
| Engine Rated Speed | 2200 | rpm |
| Operating Weight | 15500 | kg |
| Blade Length | 3965 | mm |
| Blade Height | 610 | mm |
| Maximum Drawbar Pull | ≥82 | kN |
| Forward Speed (6 gears) | 5 / 8 / 13 / 20 / 30 / 43 | km/h |
| Reverse Speed (3 gears) | 5 / 13 / 30 | km/h |
| Minimum Turning Radius | 7.8 | m |
| Wheelbase | 6100 | mm |
| Track Width (Tread) | 2160 | mm |
| Hydraulic System Pressure | 18 | MPa |
| Fuel Tank Capacity | 280 | L |
| Overall Dimensions (L×W×H) | 8900 × 2625 × 3420 | mm |
| Transmission Type | Powershift | — |
| Service Brake Type | Oil-bath multi-disc hydraulic | — |
The XCMG GR180II Series 3 motor grader is the ideal tool for the construction and maintenance of roads, highways, and urban streets. Its ability to make precise cuts and spread materials evenly makes it an indispensable piece of equipment for any medium- to large-scale road project.
In the heavy construction sector, this model stands out for its versatility in site preparation for foundations, leveling industrial platforms, and shaping slopes with precise angles. The GR180II ensures proper compaction and stability of the subgrade.
Mining and quarrying operations benefit from the GR180II’s rugged design for maintaining haul roads, clearing work sites, and grading benches. Its reinforced structure withstands the abrasive and demanding conditions typical of these production environments.
In airport infrastructure projects, the GR180II’s leveling accuracy meets the strict tolerances required for runways and aircraft aprons, where every millimeter counts to ensure operational safety.
Road Construction
Roads and highways
Industrial Platforms
Precision leveling
Mining and Quarrying
Transport routes
Airport Infrastructure
Runways and aprons
The GR180II Series 3 features an electronic control system that optimizes engine and transmission response in real time, automatically adapting to changes in load and terrain. This intelligent technology maximizes productivity and minimizes wear on mechanical components.
The ergonomic design of the operator’s cab has been carefully engineered to reduce fatigue during long shifts. Intuitive controls, excellent all-around visibility, and the automatic climate control system create a comfortable and safe working environment for the crew.
Ease of maintenance is another key feature of the GR180II. Service points are strategically located to facilitate quick access, reducing downtime caused by preventive maintenance. The modular design allows for quick and efficient technical interventions.
The GR180II Series 3’s powertrain delivers superior traction on challenging terrain thanks to its all-wheel-drive system with a limited-slip differential. This feature provides exceptional grip on loose, muddy, or steep surfaces while maintaining stability.
The GR180II maintenance program has been designed to maximize the machine’s operational availability. Extended service intervals and the quality of genuine XCMG components ensure a long service life with highly competitive operating costs in the market.
High-capacity filters and the centralized lubrication system ensure optimal protection for all critical components, reducing internal friction and preventing premature wear under continuous and demanding operating conditions.
The availability of genuine replacement parts and specialized technical support complement the value proposition of the GR180II Series 3, providing peace of mind to owners and fleet managers who require maximum reliability in their construction and earthmoving equipment.
The XCMG GR180II Series 3 motor grader complies with international emissions standards and incorporates technologies that significantly reduce its environmental footprint during operation. The optimized combustion system reduces emissions of gaseous and particulate pollutants into the environment.
Low fuel consumption not only translates into cost savings for the operator, but also helps conserve natural resources and reduce reliance on fossil fuels in the global construction and infrastructure sector.
