The D560XE heavy-duty crawler bulldozer from XCMG redefines productivity in extreme mining, quarrying, and major infrastructure projects. This 560-horsepower powerhouse combines immense pushing force with intelligent control systems to move massive volumes of earth efficiently and reliably. Every component of the D560XE is engineered to withstand the harshest operating conditions while keeping operator comfort and maintenance simplicity at the forefront.
With a reinforced mainframe, advanced hydrostatic steering, and a high-capacity blade, the D560XE delivers exceptional traction and material handling capability. Contractors worldwide trust this machine for its ability to maintain peak performance on steep grades, in abrasive soils, and during continuous multi-shift operations without compromise.
XCMG D560XE Crawler Bulldozer
The D560XE represents XCMG’s commitment to building machinery that performs flawlessly in the world’s most demanding environments. Developed through extensive field testing and operator feedback, this bulldozer incorporates a high-torque diesel engine, a rugged undercarriage, and an advanced hydraulic system to deliver class-leading push force and maneuverability. It is purpose-built to slash cycle times on large-scale earthmoving tasks while minimizing fuel burn per cubic meter moved.
At its core is a 560-horsepower turbocharged engine that provides ample reserve power for ripping compacted overburden and dozing heavy materials. The engine’s electronic fuel management system adapts to load fluctuations instantly, ensuring consistent power delivery while meeting stringent emission regulations. This means the D560XE can operate legally and efficiently in regulated markets without sacrificing output.
The powershift transmission with three forward and three reverse speeds enables smooth directional shifts under full load. Combined with a torque converter that automatically multiplies effort when resistance increases, the drivetrain protects itself from shock loads while maximizing tractive force. Operators can confidently push through challenging terrain without worrying about power interruptions or excessive wear.
The D560XE generates a maximum drawbar pull of over 650 kN, enabling it to handle heavy ripping and aggressive dozing with ease. The long track frame and optimized weight distribution place maximum tractive force on the ground, reducing track slip even on loose or wet surfaces. This traction advantage translates directly into higher productivity per pass.
Sealed and lubricated track chains with induction-hardened pins and bushings dramatically extend undercarriage life. Eight bottom rollers per side distribute the machine’s weight evenly, minimizing ground pressure while enhancing stability. The track shoe width options allow the D560XE to be configured for everything from hard rock to soft, marshy terrain.
Dual-path hydrostatic drive to each track eliminates traditional steering clutches and brakes, giving the operator infinite speed control on both sides. The result is smooth, powerful turns that maintain blade load and reduce the need for counter-rotation in tight spaces. This system also improves overall efficiency by eliminating the parasitic losses of conventional steering components.
| Parameter | Specification |
|---|---|
| Model | D560XE Crawler Bulldozer |
| Brand | XCMG |
| Engine Model | Cummins QSK19-C560 / Weichai WP15G |
| Rated Power | 560 HP / 418 kW @ 2,000 rpm |
| Max Torque | 2,350 Nm @ 1,400 rpm |
| Operating Weight | 63,500 kg (140,000 lbs) |
| Blade Capacity (Semi-U) | 22.5 m³ (29.4 yd³) |
| Blade Width | 4,500 mm (177.2 in) |
| Blade Height | 2,120 mm (83.5 in) |
| Max Drawbar Pull | 655 kN |
| Ground Pressure | 0.098 MPa (14.2 psi) |
| Overall Length | 9,350 mm (368.1 in) |
| Overall Width | 4,500 mm (177.2 in) |
| Overall Height | 4,280 mm (168.5 in) |
| Track Gauge | 2,500 mm (98.4 in) |
| Track Shoe Width | 710 mm (28 in) – optional 810 mm |
| Number of Track Rollers | 8 per side |
| Transmission Type | Powershift, 3 Forward / 3 Reverse |
| Max Speed (Forward) | 11.2 km/h (7.0 mph) |
| Max Speed (Reverse) | 13.8 km/h (8.6 mph) |
| Fuel Tank Capacity | 960 L (254 gal) |
| Hydraulic Tank Capacity | 350 L (92 gal) |
| Ripper Type (Optional) | Single shank, parallelogram design |
| Max Ripper Depth | 1,100 mm (43.3 in) |
| Blade Lift Height | 1,480 mm (58.3 in) |
| Blade Drop Depth | 680 mm (26.8 in) |
| Blade Tilt Adjustment | 520 mm (20.5 in) |
| Cooling System | Modular radiator with hydraulic fan drive |
| Emissions Standard | EU Stage V / EPA Tier 4 Final |
The D560XE thrives in open-pit mining operations where massive overburden removal and bench preparation demand constant high production. Its robust blade and ripper combination break through compacted strata with minimal passes, while the durable undercarriage withstands sharp, abrasive rock fragments that quickly wear lesser machines.
Large-scale infrastructure projects such as dam construction, airport runway earthworks, and highway corridor development rely on the D560XE for bulk cut-and-fill operations. Its ability to push heavy loads over long distances with controlled precision makes it an indispensable primary earthmover on sites where productivity targets are measured in thousands of cubic meters per shift.
Quarry reclamation and landfill engineering also benefit from the D560XE’s pushing power and stability on slopes. The machine can be equipped with a landfill blade and guarding packages that protect critical components in environments with high debris and corrosive materials, extending service intervals and protecting the investment.
The D560XE cab meets ROPS and FOPS safety standards and provides an exceptionally quiet work environment. A high-back air suspension seat with heating and ventilation reduces operator fatigue during 12-hour shifts. The panoramic windshield and sloped hood deliver outstanding forward visibility to the blade cutting edge and ripper tip.
A 10-inch color display consolidates all machine vitals, including engine load, hydraulic temperature, fuel rate, and service reminders. The system provides real-time diagnostics and can record operational data for fleet analysis. Critical alerts are displayed prominently, allowing the operator to address issues before they lead to downtime.
Standard rearview camera with distance grid lines, ground-level engine shutdown switches, and automatic parking brake activation when the operator leaves the seat are integral safety elements. Anti-slip platforms and strategically located handrails ensure secure three-point contact during machine access, even in muddy or icy conditions.
Through a combination of engine load-sensing hydraulics, engine idle shutdown, and an Eco working mode, the D560XE consumes up to 15 percent less fuel than comparable 560HP bulldozers. Over 5,000 operating hours per year, this efficiency translates into substantial operational savings and a lower total cost of ownership.
Grouped service points, extended oil change intervals of 500 hours, and easily replaceable wear parts keep the D560XE in the field longer. The tilt-up engine hood and wide-opening side doors provide unobstructed access to filters, belts, and daily checkpoints without requiring specialized tools or technician acrobatics.
XCMG’s worldwide dealer infrastructure ensures that genuine parts and expert technical support are always within reach. Regional distribution centers maintain strategic inventories of high-wear items, and certified service teams can be deployed rapidly for on-site repairs. This commitment to after-sales service maximizes the D560XE’s productive lifespan.
The D560XE engine integrates selective catalytic reduction and a diesel particulate filter to meet the latest emission standards without compromising power. An automatic engine speed reduction during idle periods further cuts fuel consumption and exhaust output. The machine is also compatible with hydrotreated vegetable oil and other sustainable fuels, offering a pathway to reduce carbon footprint on environmentally sensitive projects.
Noise levels are reduced through an insulated engine enclosure and a hydraulically driven cooling fan that operates on demand. This makes the D560XE suitable for projects near urban boundaries where strict noise ordinances must be observed. XCMG continues to refine its manufacturing processes to lower the embedded carbon of every machine delivered.
The XCMG D560XE crawler bulldozer is the definitive answer for contractors facing extreme earthmoving demands. With its 560-horsepower engine, reinforced structures, and intelligent systems, it delivers unmatched productivity and reliability where it matters most—on your job site.
