Rectangular Air Vent
Прямоугольный воздушный дефлектор
Rejilla de ventilación rectangular
The 802163675 Rectangular Air Vent is a genuine XCMG cab ventilation component engineered to provide adjustable, high‑volume airflow for operator comfort and climate control in articulated dump trucks and heavy machinery. This OEM rectangular vent, identified by part number 802163675, is manufactured from high‑impact ABS plastic with a UV‑stabilized matte black finish, and features a precision‑engineered louver system and rotating control wheel that allows operators to easily regulate air volume and direction. Designed for the demanding conditions of mining and construction, the 802163675 rectangular air vent delivers reliable performance, consistent airflow distribution, and long service life, ensuring a comfortable and productive working environment in all weather conditions.
The 802163675 Rectangular Air Vent is a critical climate control component that delivers adjustable, high‑volume airflow to the cab interior of XCMG articulated dump trucks.
This genuine XCMG vent is engineered to provide efficient air distribution, helping operators maintain comfort and focus in hot, cold, or dusty working conditions.
Its high‑impact ABS construction and UV‑stabilized finish resist cracking, fading, and degradation from sunlight and cab chemicals.
The rotary control wheel allows precise, infinite air volume adjustment, while the dual‑axis vanes enable independent horizontal and vertical airflow direction.
Tool‑free snap‑fit clips enable quick installation and removal for cleaning, inspection, or replacement.
Regular cleaning of the vent and louver assemblies ensures optimal airflow and prevents dust accumulation that can reduce efficiency.
Effective cab ventilation is essential for operator alertness, comfort, and overall well‑being during extended shifts in extreme environments.
Rectangular vents offer a larger airflow cross‑section than round vents, making them ideal for main dashboard and windshield defrost applications.
The 802163675 vent’s dual‑direction louver system allows operators to direct airflow to the face, chest, or windshield as needed for comfort and fog reduction.
A properly functioning vent system reduces the risk of heat stress and cold‑related discomfort, contributing to safer machine operation.
Replacing worn, broken, or missing vents is a simple, cost‑effective way to restore full climate control performance to the cab.
The 802163675 rectangular air vent is engineered with a focus on airflow performance, durability, and simple installation.
The rotary control wheel features an ergonomic, knurled surface for easy grip, even when wearing heavy gloves, allowing quick air volume adjustment.
The independent horizontal and vertical louver arrays are precisely moulded for smooth movement and consistent directional control, with detents for stable positioning.
The vent body incorporates a rectangular duct adaptor that reduces turbulence and pressure loss, delivering efficient airflow to the cab interior.
Integral snap‑fit clips are designed to accommodate panel thicknesses from 1.5 to 4.0 mm, ensuring a secure fit in various cab constructions.
The vent’s low‑profile flange blends seamlessly with dashboard contours, maintaining a clean, professional appearance.
The 802163675 vent is manufactured from high‑grade ABS plastic with UV stabilizers and impact modifiers, ensuring long‑term durability in demanding environments.
The matte black finish is moulded‑in, not painted, so it will not chip, peel, or fade under prolonged sunlight exposure.
The material is resistant to common cab chemicals, including cleaning agents, diesel, and hydraulic oil, preventing cracking or swelling.
When closed, the shutter provides a dust‑resistant seal that reduces ingress of fine particles, protecting the HVAC system from contamination.
All components are tested to withstand the wide temperature swings (−40°C to +85°C) typical of mining and construction operations.
The 802163675 rectangular air vent is widely used on XCMG articulated dump trucks, wheel loaders, excavators, and motor graders in surface and underground mining operations.
It is commonly installed in the cab dashboard for main cab airflow, on the windshield defrost ducts, and in side pillar locations for additional occupant comfort.
The vent is also used in auxiliary equipment such as mobile crushing plants, generator enclosures, and control cabins where robust ventilation is required.
Its standard 120 mm x 65 mm cut‑out size makes it a direct replacement for many rectangular vents used in heavy machinery.
The vent’s robust design ensures reliable performance even under high vibration levels and frequent operator adjustment.
Every 802163675 air vent is manufactured in an ISO 9001 certified facility with strict process controls and full material traceability.
Incoming ABS resin is tested for melt flow index, impact strength, and colour consistency prior to moulding.
In‑process checks monitor moulding parameters to ensure dimensional accuracy, surface finish, and part weight consistency.
Each finished vent is inspected for smooth louver movement, positive shutter sealing, and secure snap‑clip operation.
Samples from each batch are subjected to airflow performance tests, UV exposure (1000+ hours), and thermal cycling (−40°C to +85°C).
Only vents that meet all criteria are released, guaranteeing consistent quality and reliability.
The 802163675 rectangular air vent is a direct replacement for the original vent on XCMG articulated dump trucks, including XDA30, XDA40, XDA45, XDA45U, XDA60, TA30, AD45, AD60, and many other models.
It also fits most XCMG wheel loaders, excavators, and motor graders that use a 120 mm x 65 mm rectangular cut‑out.
The vent’s snap‑fit clips accommodate panel thicknesses from 1.5 mm to 4.0 mm, covering a wide range of cab constructions.
For cross‑brand applications, measure the cut‑out size and panel thickness to verify compatibility.
Always consult your machine’s parts manual to confirm the correct part number before ordering.
Installing the 802163675 air vent is a tool‑free process that takes only seconds. If replacing, first remove the old vent.
Position the new vent into the panel cut‑out from the front, ensuring the snap‑clips align with the opening.
Press the vent firmly until the clips engage securely behind the panel. An audible click confirms correct seating.
To remove, insert a flat tool into the release slots and carefully pry the clips while pulling the vent forward.
For routine cleaning, wipe the vent with a damp cloth and mild detergent. Avoid abrasive cleaners that may scratch the surface.
Periodically check louver and shutter movement; if binding occurs, clean dust and debris from the pivot areas.
The 802163675 air vent meets UL 94 V‑0 flammability requirements, ensuring it will not contribute to fire spread in the cab.
It is manufactured in compliance with ISO 9001 quality management systems and RoHS environmental directives.
The vent’s materials are free from hazardous substances and are safe for use in enclosed operator environments.
Using genuine XCMG vents helps maintain original equipment safety, performance, and warranty compliance.
Replace damaged or missing vents promptly to ensure proper cab climate control and air quality.
Aftermarket rectangular vents often use lower‑grade plastics, poorly designed louvers, or weak clips that lead to cracking, air leakage, or premature failure.
The genuine 802163675 vent is engineered to XCMG’s exact specifications, ensuring proper fit, smooth adjustment, and long‑term durability.
Its UV‑stabilized material resists fading, cracking, and chemical attack, maintaining a professional appearance throughout its service life.
Genuine XCMG parts preserve warranty coverage and maintain the resale value of your equipment.
Choose genuine XCMG for reliable ventilation, comfort, and lasting quality.
The XCMG 802163675 Rectangular Air Vent is an essential component that delivers reliable, adjustable airflow to enhance cab climate control and operator comfort on articulated dump trucks and heavy equipment.
Its robust ABS construction, versatile louver system, and UV‑resistant finish ensure dependable performance in the harshest mining and construction environments.
By replacing worn or missing vents with genuine XCMG parts, you restore effective airflow distribution, improve operator satisfaction, and maintain the integrity of your equipment.
Always source genuine XCMG components from authorised dealers to guarantee authenticity and quality.
Choose the 802163675 rectangular air vent for dependable ventilation and long‑lasting value.
Invest in genuine XCMG – your partner in comfort and performance.
