The genuine 380602027 Front Upper Glass is an original XCMG cab component designed for GR2003 and other XCMG motor graders. This heavy‑duty laminated glass provides superior visibility and operator protection. OEM part number 380602027 guarantees exact dimensions, optical clarity, and impact resistance. The 380602027 front upper glass is manufactured from automotive‑grade laminated safety glass (PVB interlayer), offering exceptional strength against flying debris and weather elements. Using genuine 380602027 ensures perfect fitment to the cab frame, reducing wind noise and preventing water leaks. This glass is critical for maintaining a safe working environment in mining, construction, and road grading applications.
The 380602027 Front Upper Glass features a 70% visible light transmission with UV protection, reducing eye strain during long shifts. Its laminated construction holds shattered fragments in place upon impact, preventing injury to the operator. The glass is tested for extreme temperatures from -40°C to +85°C and resists delamination for over 10 years. Each unit is factory‑inspected for optical distortion, thickness uniformity, and edge finish. Choosing OEM 380602027 guarantees compatibility with XCMG’s original rubber seal and adhesive specifications.
This front upper glass is widely used on XCMG GR2003, GR2153, GR3005, and GR3505 motor graders. Its dimensions (1120 × 520 × 5.76 mm) fit the upper windshield frame perfectly. For maintenance teams, stocking the 380602027 glass reduces downtime caused by stone chips or stress cracks. The glass also includes a tinted band at the top edge to reduce sun glare.
| Parameter | Specification |
|---|---|
| OEM Number | 380602027 |
| Product Name | Front Upper Glass / Windshield Upper Section |
| Brand | XCMG (Genuine OEM) |
| Glass Type | Laminated safety glass (PVB interlayer) |
| Dimensions (W × H) | 1120 × 520 mm (44.1 × 20.5 in) |
| Thickness | 5.76 mm (2×2.5mm glass + 0.76mm PVB) |
| Weight | 8.2 kg (18.1 lbs) |
| Light Transmission | 70% (±3%) |
| UV Rejection | ≥ 99% |
| Tint | Clear with 50mm dark blue top band |
| Impact Resistance | EN 12600 Class 1B1, ANSI Z26.1 |
| Operating Temperature | -40°C to +85°C |
| Edge Finish | Ground and polished, rounded corners |
| Installation Method | Rubber gasket + urethane adhesive |
| Compatible Models | XCMG GR2003, GR2153, GR3005, GR3505, GR135, GR165, GR180 |
| Certifications | ECE R43, AS/NZS 2080, ISO 9001 |
The 380602027 Front Upper Glass uses PVB laminated construction that holds glass fragments together upon impact. This prevents flying shards that could injure the operator. The glass also withstands high‑pressure washing and sudden temperature changes without cracking.
With 70% light transmission and less than 2% distortion, the 380602027 provides a crystal‑clear view of the blade and work area. The built‑in UV filter blocks 99% of harmful rays, reducing operator fatigue and protecting interior trim from fading.
The 380602027 Front Upper Glass is tested to withstand thermal shock from -40°C to +85°C without delamination. Its edge seal prevents moisture ingress, which can cause fogging or interlayer deterioration. Aftermarket glass often fails within two years; genuine XCMG lasts over a decade.
The 380602027 is CNC‑cut to exact OEM dimensions, ensuring a perfect seal with the original rubber gasket. Installation requires no trimming or modification. The glass includes alignment marks for proper adhesive application. Replace a cracked windshield in under two hours using standard tools.
The 380602027 Front Upper Glass is the direct factory replacement for XCMG motor graders used in highway construction, mining, agricultural grading, and snow removal. It fits GR2003, GR2153, GR3005, GR3505, and also older GR135, GR165, GR180 models. The same glass is used on some XCMG soil compactors and wheel loaders with compatible cab frames. Always verify your cab version before ordering.
For fleet managers, keeping a spare 380602027 glass in stock eliminates costly downtime caused by stone damage. A cracked upper glass can reduce visibility and allow dust/rain ingress. Proactive replacement during scheduled maintenance is recommended for machines operating in rocky terrain.
Aftermarket glass often has inconsistent curvature, leading to gaps and wind noise. The genuine 380602027 Front Upper Glass is formed using original XCMG molds, ensuring a perfect curve match to the cab frame. Each batch is tested for optical distortion, impact resistance, and thermal stability. Using OEM glass preserves your warranty and maintains the cab’s structural integrity.
In a comparative test, aftermarket glass showed 30% higher distortion at the edges, causing operator eye strain. Genuine 380602027 maintained less than 1.5% distortion across the entire surface. For critical operations like fine grading, a clear view is non‑negotiable. Don’t compromise – insist on genuine XCMG.
Step 1 – Remove the old glass by cutting the urethane adhesive with a piano wire tool. Clean the frame thoroughly. Step 2 – Apply primer to the frame and allow to dry. Step 3 – Install the rubber gasket onto the 380602027 glass. Step 4 – Apply a 10mm bead of urethane adhesive to the frame, then press the glass into position using suction cups. Step 5 – Secure with tape and allow 24 hours for curing. Inspect for leaks after rain. Clean only with soft cloth and ammonia‑free glass cleaner.
Never use a metal scraper on the glass surface. Replace the glass immediately if a crack extends to the edge or if the PVB layer shows bubbles. Store spare 380602027 glass vertically in a padded crate. For extreme vibration environments, inspect the glass mounts every 500 hours.
The 380602027 Front Upper Glass complies with ECE R43 (European safety standard) and ANSI Z26.1 for construction equipment glazing. Its light transmission meets OSHA requirements for indoor/outdoor operation. Never operate a grader with a cracked upper glass – it can suddenly shatter under vibration. Always replace with genuine XCMG glass to maintain ROPS/FOPS integrity if the cab is certified.
XCMG recommends inspecting the glass seal annually. A leaking seal can cause rust in the cab frame. For high‑impact applications (quarrying, demolition), consider adding a polycarbonate outer shield. For technical datasheets or bulk pricing, use the Inquiry Now button above.
For fleet owners, the 380602027 Front Upper Glass reduces long‑term costs through durability. A single stone strike can crack a cheap aftermarket glass, but genuine XCMG glass resists impacts up to 2.5 times better (measured by ball drop test). By standardizing on OEM glass, you reduce replacement frequency and labor costs. Bulk packs of 5 or 10 glasses are available – contact sales via the buttons above. Many rental companies pre‑install a protective film on new glass to extend service life.
Operator feedback emphasizes how the genuine 380602027 reduces glare and eye fatigue. The factory‑tinted top band blocks low‑angle sun without obstructing the view of the blade. Training operators to avoid slamming the cab door (which can stress the glass) reduces breakage by 60%. In conclusion, the 380602027 Front Upper Glass is a critical safety and comfort component for XCMG motor graders. Its laminated construction, optical precision, and perfect fit make it the only choice for professional maintenance. Order genuine XCMG part 380602027 today via the buttons above and ensure your operators have a clear, safe view of the job site.
