XCMG Horizontal Directional Drill Rig Chassis Assembly

Introduction
The XCMG Horizontal Directional Drill Rig Chassis Assembly serves as the robust foundation for the entire drilling system, providing stability, mobility, and structural integrity during horizontal directional drilling (HDD) operations. Engineered with precision and durability in mind, this assembly integrates a network of components designed to withstand heavy loads, vibrations, and harsh worksite environments.

Product Description of XCMG Horizontal Directional Drill Rig Chassis Assembly

Structural Framework and Core Components
The Traveling frame forms the backbone of the chassis, crafted from high-strength steel to bear the weight of the drill rig and distribute forces evenly. It connects to various sub-systems via a series of Shafts, which are secured in place using Bolts, Nuts, and Washers. The Power shelf, a critical attachment point, supports essential power generation and control units, fastened firmly with Bolt and Washer combinations to ensure stability under dynamic loads.
Mobility and Stabilization Features
The Left stabilizer leg and Right stabilizer leg enhance the rig’s stability during drilling operations. These legs are adjustable and can be extended to level the rig on uneven terrain, with Screws and Nylon blocks enabling precise positioning. An Over-wall sheath protects the legs from abrasion and environmental damage, while Stoppers prevent over-extension, ensuring safety and reliability. The legs are mounted to the traveling frame using Bolts, Washers, and Nuts, providing a secure connection.
Lubrication and Protection
Oil cups are strategically placed to lubricate moving parts, such as the shafts, reducing friction and extending component lifespan. A Baffle plate, secured with Bolts and Washers, shields vital components from debris, moisture, and accidental impacts. This plate enhances the overall durability of the chassis by safeguarding internal mechanisms from external hazards.
Fastening and Assembly Precision
The assembly utilizes specific components like the Round nut M45 x 1.5 and Washer 45 for high-stress connections, ensuring a tight and reliable fit. Smaller components, such as Washer 16, are used in conjunction with Bolts for secondary attachments, maintaining structural integrity across all interfaces. The Tank bracket, which supports hydraulic or fuel tanks, is firmly anchored with Bolt, Washer, and Nut combinations, preventing any movement that could disrupt fluid systems.
Engineering Excellence for Durability
Each component in the XCMG Chassis Assembly undergoes rigorous testing for tensile strength, corrosion resistance, and fatigue life. The use of high-quality materials, combined with precision machining and standardized fasteners, ensures easy maintenance and replacement. The assembly’s design prioritizes compatibility with other drill rig systems, enabling seamless integration and optimized performance in HDD projects.
Conclusion: The Bedrock of HDD Operations
The XCMG Horizontal Directional Drill Rig Chassis Assembly delivers the stability, functionality, and longevity required for successful horizontal directional drilling. By integrating robust structural elements, advanced stabilization features, and meticulous engineering, it provides operators with a reliable platform to execute complex drilling tasks with confidence. Trusted by professionals worldwide, this chassis assembly exemplifies XCMG’s commitment to excellence in construction machinery.

Product Parameters of XCMG Horizontal Directional Drill Rig Chassis Assembly

No.	PartNumber	Part Name	Q’ty	Remark
1	805238669	Round nut M45 x 1.5	2	GB/T812
2	805300095	Washer 45	2	GB/T858
3	425101517	Traveling frame	1
4	425101080	Shaft	1
5	425101081	Stopper	5
6	805300011	Washer 16	5	GB/T93
7	805000013	Bolt	5	GB/T5783
8	801100336	Oil cup	1	JB/T7940.1
9	425101085	Bolt	1
10	425101082	Shaft	1
11	805200052	Nut	24	GB/T6170
12	805300023	Washer	44	GB/T93
13	805001904	Bolt	44	GB/T5782
14	425101083	Shaft	4
15	805000022	Bolt	4	GB/T5783
16	805300013	Washer	4	GB/T97.1
17	425500378	Baffle plate	2
18	805000714	Bolt	4	GB/T5783
19	805300014	Washer	4	GB/T93
20	425500377	Shaft	2
21	425500902	Left stabilizer leg	1
22	805100525	Screw	4	GB/T68
23	425101086	Nylon block	1
24	801970417	Over-wall sheath	1
25	425500913	Right stabilizer leg	1
26	425101084	Tank bracket	1
27	805000716	Bolt	9	GB/T5783
28	805300018	Washer	9	GB/T93
29	805203629	Nut	6	GB/T6170
30	425101079	Power shelf	1
31	801970416	Sheathed	1
